Поз.
Артикул
Описание
83
TANK IN ENGINE TUNNEL
91
RADIATOR CAP
93
GASKET O.D., 37 MM
391
BRACKET
399
CLAMP , Replaced By: N916016011202
399
CLAMP AT BRACKET
399
CLAMP , Replaced By: A3609951201
399
CLAMP OIL-DIPSTICK GUIDE TUBE TO BRACKET
415
SCREW , Replaced By: N304017008021
415
SCREW PIPE CLAMP
427
NUT , Replaced By: N913004008001
427
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
435
SUPPORT EXPANSION TANK
442
BRACKET STRUT TO CROSS MEMBER
449
NUT , Replaced By: N910113010000
449
NUT STRAP TO BRACKET
457
PAD EXPANSION TANK TO SUPPORT
465
BRACKET (STRAP)
472
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
472
NUT , Replaced By: N913004008001
479
HOSE DE-AERATION LINE, LENGTH AVAILABLE: 1000 MM
479
HOSE FROM RADIATOR EXPANSION TANK TO EXPANSION TANK IN ENGINE TUNNEL 8X17 MM, ORDER BY THE METER
487
BREATHER PIPE FROM RADIATOR EXPANSION TANK TO EXPANSION TANK IN ENGINE TUNNEL
495
BREATHER PIPE FROM RADIATOR EXPANSION TANK TO EXPANSION TANK IN ENGINE TUNNEL
503
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
503
CLAMP , Replaced By: N916017011001
527
BRACKET OVERFLOW LINE TO BRACKET AT TRANSVERSE INTAKE PIPE
529
BRACKET OVERFLOW LINE TO BRACKET AT TRANSVERSE INTAKE PIPE
535
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
535
CLAMP ,K 147121, Replaced By: N000000000319
535
CLAMP , Replaced By: N916016008200
535
CLAMP , Replaced By: A3604300143
543
SCREW PUMP TO BRACKET
543
SCREW , Replaced By: N304017006016
551
NUT PUMP TO BRACKET
551
NUT , Replaced By: N913004006001
553
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
553
CLAMP ,K 147121, Replaced By: N000000000319
553
CLAMP , Replaced By: N916016008200
553
CLAMP , Replaced By: A3604300143
555
SCREW PUMP TO BRACKET
555
SCREW , Replaced By: N304017006016
557
NUT PUMP TO BRACKET
557
NUT PUMP TO BRACKET
557
NUT , Replaced By: N913004006001
559
BRACKET FUEL LINE TO BELL HOUSING
559
BRACKET , Replaced By: A6454310740
567
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
567
CLAMP ,K 147121, Replaced By: N000000000319
567
CLAMP , Replaced By: N916016008200
567
CLAMP , Replaced By: A3604300143
575
SCREW PUMP TO BRACKET
575
SCREW , Replaced By: N304017006016
583
NUT PUMP TO BRACKET
583
NUT , Replaced By: N913004006001
591
SCREW PIPE CLAMP
591
SCREW , Replaced By: N304017008021
599
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
599
NUT , Replaced By: N913004008001
999
LINE , Replaced By: A0005516256
999
LINE12 MM, ORDER BY THE METER4 691315
999
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
999
LOOM TIE , Replaced By: N916017020000
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
999
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
CLAMP LINE MOUNTING
999
BRACKET EXPANSION TANK, 415 5 014668 416 5 000515 417 4 972023
999
TANK AT CAB REAR PANEL, 415 5 014668 416 5 000515 417 4 972023
999
CONSOLE , Replaced By: A3815000727
999
BREATHER PIPE FROM ENGINE TO EXPANSION TANK 695 MM
999
BRACKET OVERFLOW LINE TO BRACKET AT TRANSVERSE INTAKE PIPE
999
BRACKET (STRAP), 415 5 014668 416 5 000515 417 4 972023
999
BRACKET , Replaced By: A3875015820
999
COOLING WATER PIPE FROM WATER PUMP TO EXPANSION TANK
999
BRACKET , Replaced By: A3834929141
999
HOSE
999
HOSE , Replaced By: A3875012882
999
HOSE VENTILATION, FROM RADIATOR TO EXPANSION TANK, 415 5 014668 416 5 000515 417 4 972023
999
BREATHER PIPE VENTILATION, FROM RADIATOR TO EXPANSION TANK,4 367399 FOR USE WITH MERCEDES-BENZ CAB
999
BREATHER PIPE VENTILATION, FROM RADIATOR TO EXPANSION TANK 1115 MM,4 635938
999
BREATHER PIPE VENTILATION, FROM RADIATOR TO EXPANSION TANK, 415 5 014668 416 5 000515 417 4 972023 FOR USE WITH SHORT MERCEDES-BENZ CAB
999
BREATHER PIPE VENTILATION, FROM RADIATOR TO EXPANSION TANK, 415 5 014668 416 5 000515 417 4 972023 FOR USE WITH SHORT MERCEDES-BENZ CAB
999
BREATHER PIPE , Replaced By: N900271015080
999
BREATHER PIPE VENTILATION, FROM RADIATOR TO EXPANSION TANK 1215 MM, FOR USE WITH MERCEDES-BENZ CAB,FROM IDENT NO.4 282787
999
BRACKET , Replaced By: A3524290740
999
BRACKET , Replaced By: A6454310740
999
BREATHER PIPE FROM ENGINE TO EXPANSION TANK, 415 5 014668 416 5 000515 417 4 972023
999
BREATHER PIPE FROM ENGINE TO EXPANSION TANK 1055 MM, FOR USE WITH MERCEDES-BENZ CAB4 635939
999
CLAMP COOLING WATER LINE TO BRACKET,5 022370
