Поз.
Артикул
Описание
4
CLUTCH PRESSURE PLATE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
4
CLUTCH PRESSURE PLATE , Replaced By: A0032502504
12
HOUSING
20
SPRING SUSPENDED BELOW LEAF SPRING
20
SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
24
CLAMP RELEASE FLANGE TO RELEASE LEVER
28
PRESSURE PLATE
34
RELEASE LEVER CLUTCH ACTUATION
37
SPINDLE FOR BEDDING THE LEVERS IN CLUTCH PRESSURE PLATE
40
SPINDLE FOR BEDDING THE LEVERS IN BRACKETS
40
SPINDLE , Replaced By: A0002522816, +001A1249945241
43
ROLLER FOR BEDDING THE LEVERS IN BRACKETS
46
BRACKET RELEASE LEVER
49
LOCK PLATE LEVER TO BRACKET
49
LOCK PLATE RELEASE LEVER TO SHAFT
58
FLANGE
58
FLANGE , Replaced By: A0002522145
64
SPRING , Replaced By: A0002523227
64
SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
64
SPRING SUSPENDED BELOW LEAF SPRING
67
PRESSURE SPRING SPRING STEEL WIRE DIA., 3.75 MM
70
PRESSURE SPRING SPRING STEEL WIRE DIA., 4.00 MM
73
LEAF SPRING THIGH SPRING SUSPENDED BELOW LEAF SPRING
73
LEAF SPRING THIGH SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
76
NUT FOR BRACKETS
76
NUT , Replaced By: A0002523072
79
LOCK FOR BRACKETS
82
LOCK WASHER BRACKET TO STEERING COLUMN END
85
SCREW RELEASE LEVER,BRACKET
88
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
91
SCREW , Replaced By: N304017010055
91
SCREW , Replaced By: N304017010050
97
CLUTCH DISC , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0072500803
97
CLUTCH DISC , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0062504603
97
CLUTCH DISC , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0062504503
97
CLUTCH DISC , Replaced By: A0052506403
97
CLUTCH DISC ASBESTOS-FREE LINING
97
CLUTCH DISC ASBESTOS-FREE LINING, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
97
CLUTCH DISC
97
CLUTCH DISC
103
LEAF SPRING
103
LEAF SPRING , REBORE HOLE IN SUPPORTING PLATE FROM 5.2MM TO 6.2MM, Replaced By: A0002523819, +002A0002523975
109
RIVET , Replaced By: A0002522075
109
RIVET LEAF SPRING TO CLUTCH DISC
109
RIVET LEAF SPRING TO CLUTCH DISC 5X6 MM
112
CLUTCH LINING ASBESTOS-FREE
112
CLUTCH LINING , Replaced By: A0012522910
112
CLUTCH LINING , Replaced By: A0012522910
112
CLUTCH LINING
118
RIVET LINING WITH INTERMEDIATE SPRING
118
RIVET , Replaced By: A0002521275
118
RIVET LINING WITH INTERMEDIATE SPRING,5 563495
124
RIVET LINING WITH CLUTCH DISC,5 563495
124
RIVET LEAF SPRING TO CLUTCH DISC
999
LOCK WASHER BELL HOUSING TO TRANSMISSION
999
SNAP RING LEVER TO RELEASE SHAFT,4 601609
999
SCREW , Replaced By: N308676018010
999
LOCK RINGTO 000 553 37 01,000 553 39 01,
999
WASHER RADIATOR TO RUBBER MOUNTING
999
WASHER , Replaced By: N000125010532
999
GREASE NIPPLE (PARTS KIT) RELEASE BEARING LUBRICATION
999
LEVER (PARTS KIT),CLUTCH ACTUATION
999
REPAIR KIT , Replaced By: A3892500014
999
SHAFT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 285575, Replaced By: A3852500014
999
BUSHING ,4 401411, Replaced By: A3852510450, +001A0119978846
999
SHAFT (PARTS KIT),RELEASE SHAFT
999
VALVE CLUTCH SLAVE CYLINDER
999
SEAL RING LEVER TO RELEASE SHAFT,5 285575
999
SEAL RING CLUTCH ACTUATION
999
SEAL RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0019972141
999
VALVE , Replaced By: A3075530107
999
SLAVE CYLINDER ,4 601609, Replaced By: A0012950307, +001A6202900534, +001A0009966440
999
CLAMP , Replaced By: A0002523227
999
PRESSURE PLATE
999
PLUG BELL HOUSING
