Поз.
Артикул
Описание
5
CLAMP , Replaced By: A3129952420
8
SCREW CAP TO BRACKET
11
WASHER PLUG SOCKET TO BRACKET
14
LOCK WASHER CABLE TO FUSE BOX
15
NUT
56
BRACKET TO ENGINE
59
BRACKET LINE MOUNTING
62
SCREW MOUNTING CLAMP TO BRACKET AND TO FRAME
65
WASHER TRAILER PLUG SOCKET TO BRACKET
68
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
71
BRACKET COMPRESSED AIR LINE, BRAKE
71
BRACKET COMPRESSED AIR LINE TO BRAKE CYLINDER
74
CLAMP , Replaced By: A6739950001
74
CLAMP DELIVERY AND SUCTION LINES TO FRAME 12/15
74
CLAMP DELIVERY AND SUCTION LINES TO FRAME 12/15
74
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
77
SCREW CAP TO BRACKET
78
WASHER PLUG SOCKET TO BRACKET
80
LOCK WASHER CABLE TO FUSE BOX
83
NUT
89
BRACKET AT CROSS MEMBER
92
LOOM TIE WIRING HARNESS FOR AIR CONDITIONING SYSTEM 205 MM
92
LOOM TIE LINE MOUNTING
92
LOOM TIE ELECTRIC CABLE MOUNTING
95
WASHER BRACKET TO LEFT SIDE MEMBER
95
WASHER , Replaced By: A3609902340
101
WASHER BRACKET TO CAB REAR PANEL
140
ADAPTER FITTING , Replaced By: A0004296934
143
TOOTHED WASHER SENDER UNIT TO BRACKET
146
NUT BRACKET TO SIDE MEMBER
149
BRAKE HOSE FROM QUICK-RELEASE VALVE TO COMBINATION CYLINDER,RIGHT
149
BRAKE HOSE LEFT AND RIGHT FRONT WHEEL BRAKE CYLINDERS
149
BRAKE HOSE LEFT AND RIGHT FRONT WHEEL BRAKE CYLINDERS
149
BRAKE HOSE LEFT AND RIGHT FRONT WHEEL BRAKE CYLINDERS
155
FITTING BRAKE HOSE TO COMPRESSED AIR LINE
155
CONNECTION FITTING
158
LINE LEFT FRONT WHEEL BRAKE CYLINDER 12X1 MM
158
LINE RIGHT FRONT WHEEL BRAKE CYLINDER 12X1 MM
161
UNION NUT LINE CONNECTION, Replaced By: N000000006239
164
GLAND , Replaced By: A0019901967
167
T-FITTING DIAPHRAGM CYLINDER,CONNECTION: "11",5 272559
170
TEST CONNECTION TIRE INFLATING CONNECTION KNORR
170
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
173
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
176
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
179
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
179
THRUST RING LOCKING VALVE
179
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
221
BRAKE HOSE LEFT AND RIGHT FRONT WHEEL BRAKE CYLINDERS
221
BRAKE HOSE REAR AXLE RELAY VALVE
221
BRAKE HOSE FROM COMPRESSED AIR LINE TO REAR WHEEL BRAKE CYLINDER,D 030552
221
BRAKE HOSE FROM COMPRESSED AIR LINE TO REAR WHEEL BRAKE CYLINDER,D 030552
221
BRAKE HOSE LEFT AND RIGHT FRONT WHEEL BRAKE CYLINDERS
221
BRAKE HOSE FROM QUICK-RELEASE VALVE TO COMBINATION CYLINDER,RIGHT
221
BRAKE HOSE FROM COMPRESSED AIR LINE TO REAR WHEEL BRAKE CYLINDER,D 030552
221
BRAKE HOSE LEFT AND RIGHT FRONT WHEEL BRAKE CYLINDERS
224
T-FITTING TRAILER CONTROL VALVE,CONNECTION: "1"
224
T-FITTING AIR RESERVOIR,CONNECTION: "31"
227
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
230
THRUST RING LOCKING VALVE
230
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
230
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
233
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
236
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
239
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
242
TEST CONNECTION TIRE INFLATING CONNECTION KNORR
242
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
