Поз.
Артикул
Описание
90
SUPPORT RADIATOR MOUNTING,4 428845
114
RUBBER MOUNTING RADIATOR MOUNTING,4 428845
126
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
132
SPRING WASHER STEERING COLUMN BRACKET TO CAB
138
SCREW REAR EXHAUST PIPE TO MUFFLER
138
SCREW EXHAUST PIPE TO BRACKET
144
SPRING WASHER STEERING COLUMN BRACKET TO CAB
150
WASHER , Replaced By: N000125010532
150
WASHER RADIATOR TO RUBBER MOUNTING
162
FAN SHROUD , 0-199 FROM CHASSIS 4 428845, 200-599 FROM CHASSIS 4 424216
168
SCREW , Replaced By: N304017006016
168
SCREW PUMP TO BRACKET
174
WASHER AIR BAFFLE AND BRACKET TO RADIATOR
180
SPRING WASHER LICENSE PLATE TO BRACKET
186
CLIP-TYPE NUT FAN SHROUD TO RADIATOR
396
HOSE FROM RADIATOR TO THERMOSTAT
408
CLAMP , Replaced By: N000000000671
408
CLAMP
414
CLAMP , Replaced By: N000000000672
414
CLAMP HOSE FASTENING 50-70X13 MM
426
HOSE FROM EXPANSION TANK TO THERMOSTAT
432
CLAMP HOSE TO FITTING AND TO OIL TANK
432
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
479
CLAMP , Replaced By: N000000000672
479
CLAMP HOSE FASTENING 50-70X13 MM
479
CLAMP HOSE FASTENING 50-70X13 MM
480
CLAMP , Replaced By: N000000000671
480
CLAMP
485
CLAMP , Replaced By: N000000000667
485
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
486
CLAMP , Replaced By: N000000000670
486
CLAMP
618
HOSE FROM BUBBLE SEPARATOR TO HEATING PIPE 18X27 MM, ORDER BY THE METER
624
CLAMP , Replaced By: N000000000667
624
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
999
RADIATOR , Replaced By: A0015010901
