Поз.
Артикул
Описание
7
RADIATOR WATER BEHR
7
RADIATOR WATER BEHR
11
TANK EXPANSION TANK
11
TANK ON RADIATOR
17
RADIATOR CAP CENTRAL
17
RADIATOR CAP CENTRAL
23
RADIATOR CAP FILLER NECK
23
RADIATOR CAP FILLER NECK
25
GASKET O.D., 52 MM
27
GASKET O.D., 37 MM
29
SCREW PLUG WATER DRAIN
29
SCREW PLUG , Replaced By: N007604014101
35
SEAL RING FUEL LINE TO FEED PUMP
41
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
41
SCREW , Replaced By: N304017008016
47
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
53
WASHER EXHAUST MUFFLER TO STRAP
53
WASHER , Replaced By: N000125008443
59
HOSE OVERFLOW, EXPANSION TANK
65
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
65
CLAMP , Replaced By: N916017011001
65
CLAMP , Replaced By: N916017011000
132
FAN SHROUD RADIATOR
133
SCREW COVER PLATE TO BRACKET
134
SPRING WASHER LICENSE PLATE TO BRACKET
135
WASHER AIR BAFFLE AND BRACKET TO RADIATOR
999
BRACKET OIL DIPSTICK TO RADIATOR
