Поз.
Артикул
Описание
32
CONNECTOR FRONT EXHAUST PIPE,RIGHT
158
EXHAUST PIPE FRONT,REAR RIGHT PART,5 193595
240
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
252
SCREW BRACKET TO SIDE MEMBER
252
SCREW , Replaced By: N304017010002
264
NUT STRAP TO BRACKET
264
NUT , Replaced By: N910113010000
496
REAR EXHAUST PIPE TAIL PIPE,FRONT,5 193595
688
BRACKET REAR EXHAUST PIPE
750
SCREW , Replaced By: N304017008034
750
SCREW BRACKET TO CROSS CONNECTION STRUT
770
NUT , Replaced By: N913004008001
770
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
770
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
790
CLAMP EXHAUST PIPE TO BRACKET
790
CLAMP , Replaced By: A6454921140
795
SCREW , Replaced By: N304017010002
795
SCREW BRACKET TO SIDE MEMBER
800
NUT , Replaced By: N910113010000
800
NUT STRAP TO BRACKET
999
NUT
999
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
999
CLAMP , Replaced By: N071555090502
999
SCREW BRACKET TO SIDE MEMBER M 12X40
999
BRACKET FRONT AND REAR EXHAUST MUFFLERS,5 765950
999
PROTECTIVE PLATE FUEL TANK
999
WASHER INTERMEDIATE SPEED STOP
