Поз.
Артикул
Описание
190
REAR SPRING (PARABOLIC SPRING),3-LEAF, WITH 2-LEAF HELPER SPRING,K 083473
190
REAR SPRING (PARABOLIC SPRING),3-LEAF, WITH 2-LEAF HELPER SPRING,5 359429
204
BUSHING
204
BUSHING
208
SPACER REAR SPRING
208
SPACER
212
SHIM REAR SPRING
212
SHIM REAR SPRING
216
SPRING BOLT
216
SCREW
216
SPRING BOLT , Replaced By: A9433210271
220
NUT TORSION BAR TO BEARING BRACKET,5 904661
224
SPRING CLAMP REAR SPRING
224
SPRING CLAMP , Replaced By: A6203240033
228
SCREW STRUT TO BUMPER
228
SCREW , Replaced By: A0079900601
232
NUT SUPPORT TO SIDE MEMBER
236
RIVET SPRING CLAMP TO SPRING LEAF,5 940410
240
BOLT SPRING SHACKLE TO SPRING REAR BRACKET
244
WASHER RADIATOR TO RUBBER MOUNTING
244
WASHER , Replaced By: N000125010532
248
NUT STRAP TO BRACKET
248
NUT , Replaced By: N910113010000
252
SPRING CLAMPING PLATE REAR SPRING TO REAR AXLE
252
SPRING CLAMPING PLATE REAR SPRING TO REAR AXLE
256
U-BOLT REAR AXLE TO TO REAR SPRINGS 475 MM,4 941583
256
U-BOLT , Replaced By: A9433510225, +002N910113024000
256
U-BOLT REAR AXLE TO TO REAR SPRINGS 500 MM,4 941582
260
PAD BETWEEN SPRING AND REAR AXLE,5 507219
264
PIN BEARING BRACKET
268
WASHER STEEL VERSION
272
NUT U-BOLT
276
SHACKLE REAR SPRING
276
SHACKLE , Replaced By: A6213250020, +002A3353240050
280
BUSHING
284
GREASE NIPPLE FOR SPRING
288
THRUST WASHER SHACKLE TO REAR-SPRING REAR BRACKET, INSIDE
292
THRUST WASHER SHACKLE TO REAR-SPRING REAR BRACKET, OUTSIDE
296
SEAL RING SHACKLE TO REAR-SPRING REAR BRACKET
300
NUT SHACKLE TO REAR-SPRING REAR BRACKET
304
SHACKLE PIN (PARTS KIT),REAR SPRING EYE, ON RELOCATION OF SPRING SHACKLES,SUPPLY ADDITIONALLY:2X 335 324 00 50
304
REPAIR KIT , Replaced By: A3893200065
304
SHACKLE PIN (PARTS KIT),FRONT SPRING EYE
308
GREASE NIPPLE PROTECTIVE TUBE
312
WASHER FRONT SPRING TO SPRING SHACKLE & SPRING BRACKETS
312
WASHER SHACKLE PIN, AS REQUIRED 4.0 MM
316
SEAL RING SPRING SHACKLE TO SPRING REAR BRACKET
332
BEARING BRACKET SHACKLE TO FRAME,5 904660
332
CONSOLE , Replaced By: A3933261163, +001N000961016081
334
STUD BOLT
336
SPRING WASHER BRACKET TO TIMING CASE
340
SCREW BRACKET TO SUPPORT
344
SHACKLE STABILIZER,5 904660
348
BUSHING SHACKLE TO BEARING BRACKET,5 904660
352
SPACER WASHER SHACKLE TO BEARING BRACKET,5 904660
356
SPACER WASHER SHACKLE TO BEARING BRACKET,5 904660
360
NUT COMBINATION CYLINDER TO BEARING BRACKET
360
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
364
TORSION BAR REAR AXLE
366
RUBBER MOUNTING SHACKLE TO TORSION BAR,5 904660
368
REPAIR KIT TORSION BAR MOUNTING
372
LOCK RING SHACKLE TO TORSION BAR,5 904660
376
BEARING TORSION BAR AND SHOCK ABSORBER,RIGHT
376
BEARING TORSION BAR AND SHOCK ABSORBER,LEFT
388
BUSHING TORSION BAR TO BEARING BRACKET,5 184731
392
WASHER BRACKET TO SPARE WHEEL CARRIER
396
NUT INTERMEDIATE LEVER TO STEERING SUPPORT
396
NUT , Replaced By: N910113018004
400
SHOCK ABSORBER PARTS KIT
404
RETAINER SHOCK ABSORBER,BOTTOM
408
SPACER TUBE SHOCK ABSORBER TO CROSS MEMBER AND TO BEARING
412
RUBBER BUFFER SHOCK ABSORBER TO BEARING BRACKET
416
RETAINER SHOCK ABSORBER,BOTTOM
420
NUT BRACKET TO SIDE MEMBER
420
NUT , Replaced By: N910113014001
999
SPACER TUBE SPRING CLAMP
999
SHOCK ABSORBER , Replaced By: A0043230100
999
THRUST WASHER , Replaced By: A6213250062
999
THRUST WASHER , Replaced By: A6213250162
999
WASHER , Replaced By: A3523231076
999
PIN TORSION BAR TO BEARING BRACKET
999
CONSOLE , Replaced By: A3933200678
999
BRACKET ,4 844252, Replaced By: A6203230040, +002A3939900240, +001N000960016065
999
REPAIR KIT , Replaced By: A3953200265
999
REPAIR KIT , Replaced By: A3953200165
999
PIN , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6205860232
999
SCREW , Replaced By: N308676012038
999
SCREW SHACKLE TO CONSOLE
999
SCREW BRACKET TO TRANSMISSION
