Поз.
Артикул
Описание
231
BATTERY , Replaced By: A0035410901
231
BATTERY , Replaced By: A0035418801
231
BATTERY12V/120 AH
231
BATTERY12 V/115 AH
291
SCREW BRACKET TO CAB CONSOLE,K 035197
291
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
307
NUT , Replaced By: N910113014001
307
NUT BRACKET TO SIDE MEMBER
315
ELECTRIC CABLE , Replaced By: A6735460013
315
ELECTRIC CABLE FROM BATTERY POS.POLE TO STARTING MOTOR 70 MM2, ORDER BY THE METER
317
SOLDERING TERMINAL BATTERY POS. POLE 70 MM2
319
CABLE SHOE BATTERY CABLE 10-70 MM
319
CABLE SHOE BATTERY CABLE 12-70 MM
321
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
321
LOCK WASHER FITTING TO BRACKET
323
NUT BRACKET TO SUPPORT AND TO END PIECE
323
NUT STRAP TO SUPPORT,5 149419
324
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
325
NUT BALL PIVOT TO LEVER
327
ELECTRIC CABLE , Replaced By: N922002070000
327
ELECTRIC CABLE , Replaced By: A6735460013
327
ELECTRIC CABLE FROM BATTERY POS.POLE TO STARTING MOTOR 70 MM2, ORDER BY THE METER
329
SOLDERING TERMINAL BATTERY POS. POLE 70 MM2
331
SOLDERING TERMINAL BATTERY NEG. POLE 70 MM2
335
ELECTRIC CABLE , Replaced By: A6735460013
335
ELECTRIC CABLE FROM BATTERY POS.POLE TO STARTING MOTOR 70 MM2, ORDER BY THE METER
337
SOLDERING TERMINAL POS. POLE
339
CABLE SHOE BATTERY CABLE 10-70 MM
341
SCREW EXHAUST PIPE TO BRACKET
343
WASHER , Replaced By: N009021010209
343
WASHER BRACKET TO COVERING
345
NUT , Replaced By: N910113010000
345
NUT STRAP TO BRACKET
347
GROUND STRAP , Replaced By: A3525400041
347
GROUND STRAP FROM STARTING MOTOR TO SIDE MEMBER,5 193595
349
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
351
NUT BRACKET TO SUPPORT AND TO END PIECE
353
SCREW REAR EXHAUST PIPE TO MUFFLER
355
WASHER , Replaced By: N009021010209
355
WASHER BRACKET TO COVERING
359
NUT , Replaced By: N910113010000
359
NUT STRAP TO BRACKET
361
NEG. CABLE FROM FRAME CROSS MEMBER TO CAB
363
SCREW , Replaced By: N304017008034
363
SCREW BRACKET TO CROSS CONNECTION STRUT
365
SCREW , Replaced By: N304017008016
365
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
367
WASHER , Replaced By: N000125008443
367
WASHER EXHAUST MUFFLER TO STRAP
369
NUT , Replaced By: N913004008001
369
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
369
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
GROMMET BATTERY CASE
999
BOOT
999
GROMMET FUEL LINE THRU FRAME SIDE MEMBER 38/30 MM
999
GROMMET BATTERY CASE
999
LENS
999
SOCKETTO 003 542 46 16,99 16
999
PLUG HOUSING 4-POLE, MODULE "V"
999
DIAGRAM PAPER SET100 PIECES
