Поз.
Артикул
Описание
8
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
12
FITTING (PARTS KIT),LINE RUPTURE
12
FITTING , Replaced By: A0029905971
13
UNION NUT LINE CONNECTION
14
GLAND LINE CONNECTION
15
SLEEVE LINE CONNECTION
16
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
16
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
20
PLASTIC PIPE RISING PIPE 4X6 MM
20
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
22
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
24
UNION NUT BLEEDING, FROM IDENT NO. 5 033767,EXCEPT FOR 5 039977
32
GLAND BLEEDING, FROM IDENT NO. 5 033767,EXCEPT FOR 5 039977
40
SLEEVE LEAK LINE
44
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
48
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
56
FITTING LINE CONNECTION TO FIRE WALL,5 726664
59
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
59
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
60
SEAL RING , Replaced By: A0009940747
60
LOCK RING LINE CONNECTION
61
LOCK , Replaced By: A0009945448
61
LOCK LINE CONNECTION
62
REPAIR KIT , Replaced By: A0309971748
62
REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
68
TS DOUBLE FITTING (PARTS KIT),LINE RUPTURE 4MM
244
SWITCH TORQUE REDUCER
244
SWITCH , Replaced By: A0015452709
244
SWITCH , Replaced By: A0015451109
244
SWITCH , Replaced By: A0005459009
244
SWITCH , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 360728, Replaced By: A0005457909
252
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 3.00 MM
252
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 2.80 MM
252
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 2.60 MM
252
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 2.40 MM
252
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 2.20 MM
252
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 2.00 MM
252
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 1.80 MM
252
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 1.60 MM
256
SEAL RING NEUTRAL POSITION
260
PIN NEUTRAL POSITION
268
THREADED BUSHING NEUTRAL POSITION
276
SWITCH GEAR CLUSTER INDICATION
276
SWITCH , Replaced By: A0035451614
276
SWITCH , Replaced By: A0025458114
284
SEAL RING SWITCH TO CASE COVER
284
SEAL RING , Replaced By: N007603018100
292
VALVE GEAR CLUSTER SHIFT
300
CLEANERTO 000 434 22 01
308
SEAL RINGTO 000 434 23 01
316
CUP 3/2-WAY VALVE WABCO
324
HANDLETO 000 434 23 01
332
REPAIR KIT 3/2-WAY VALVE WABCO
340
HOLLOW SCREW HEATING CONNECTION
348
SEAL RING LINE CONNECTION
388
NUT SUCTION LINE TO OIL PUMP
396
LOCK WASHER VALVE TO FLOOR
404
BRACKET AT CLUTCH PEDAL UNIT
412
SCREW COVER PLATE TO BRACKET
420
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
428
WASHER COMPRESSED AIR LINE TO BRACKET
428
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
436
NUT SUCTION LINE TO OIL PUMP
444
HOLLOW SCREW LINE CONNECTION
452
SEAL RING LINE CONNECTION
460
HOLLOW SCREW HEATING CONNECTION
468
SEAL RING LINE CONNECTION
476
HOLLOW SCREW LINE CONNECTION
484
SEAL RING LINE CONNECTION
485
FITTING PRESSURE REGULATOR,CONNECTION: "40"
486
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
487
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
487
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
488
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "40"
489
HOLLOW SCREW HEATING CONNECTION
489
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
490
SEAL RING LINE CONNECTION
490
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
491
HOLLOW SCREW POWER CYLINDER
492
SEAL RING LINE CONNECTION
493
BANJO UNION STOP LIGHT
494
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
495
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
496
HOLLOW SCREW HEATING CONNECTION
496
HOLLOW SCREW LINE CONNECTION
500
SEAL RING LINE CONNECTION
508
HOLLOW SCREW LINE CONNECTION
516
SEAL RING LINE CONNECTION
524
BREATHER , Replaced By: A3933280065
524
PIPE SOCKET COMPRESSED AIR PIPING TO 3/2-WAY VALVE
532
SENDER UNIT OVERREVVING
532
SENDER UNIT OVERREVVING
532
SENDER UNIT OVERREVVING
540
SWITCH , Replaced By: A0025458114
540
SWITCH , Replaced By: A0035451614
540
SWITCH GEAR CLUSTER INDICATION
548
SEAL RING , Replaced By: N007603018100
548
SEAL RING SWITCH TO CASE COVER
556
BRACKET LINE MOUNTING
564
SHEET METAL SCREW , Replaced By: N000000000453
564
SHEET METAL SCREW MODULE TO HOUSING
572
BRACKET , Replaced By: A6205240340
572
BRACKET FUEL LINES TO TRANSMISSION
572
BRACKET FUEL LINES TO TRANSMISSION
575
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
580
LOOM TIE LINE MOUNTING
580
LOOM TIE LINE MOUNTING 280 MM
