Поз.
Артикул
Описание
104
BRACKET , Replaced By: A3874292040
104
BRACKET AT FRAME
112
BRACKET , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6204294940
120
RIVET BRACKET TO FRAME
168
SUPPORT TWO-CIRCUIT BRAKE LINE COUPLING, Replaced By: A3874321016
168
SUPPORT TWO-CIRCUIT BRAKE LINE COUPLING
176
SUPPORT , Replaced By: A3874320916
176
SUPPORT , Replaced By: A3874321616
176
SUPPORT , Replaced By: A6214320116
176
SUPPORT BRAKE LINE COUPLINGS
176
SUPPORT BRAKE LINE COUPLINGS
184
ANGLE , Replaced By: A6214320017
184
ANGLE LEFT
184
ANGLE , Replaced By: A6214320117
184
ANGLE RIGHT
192
SCREW , Replaced By: N304017008021
192
SCREW PIPE CLAMP
192
SCREW PIPE CLAMP
200
WASHER , Replaced By: N000125008443
200
WASHER EXHAUST MUFFLER TO STRAP
208
NUT , Replaced By: N913004008001
208
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
216
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
224
NUT , Replaced By: N910113010000
224
NUT STRAP TO BRACKET
232
FITTING BRAKE LINE COUPLING TO BRACKET
240
NUT BRACKET TO SIDE MEMBER
248
TEST CONNECTION , Replaced By: A0004312931
248
TEST CONNECTION
624
BRAKE LINE COUPLING SUPPLY, RED
624
BRAKE LINE COUPLING SUPPLY, RED
624
BRAKE LINE COUPLING SUPPLY, RED
632
BRAKE LINE COUPLING BRAKE,YELLOW KNORR
632
BRAKE LINE COUPLING BRAKE,YELLOW BOSCH
632
BRAKE LINE COUPLING BRAKE,YELLOW WESTINGHOUSE
640
BRAKE LINE COUPLINGTO 000 429 38 30
640
SEAL RING , Replaced By: A0004296930
640
SEAL RING"WABCO"
648
COVER"WABCO", NOT USED
656
SEAL RINGTO 000 429 38 30
664
REPAIR KITTO 000 429 37 30
664
REPAIR KITTO 000 429 63 30
664
REPAIR KITTO 000 429 78 30,4 434236
672
REPAIR KIT"KNORR"
680
FITTING BRAKE LINE COUPLING TO BRACKET
688
NUT BRACKET TO SIDE MEMBER
696
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
704
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
VALVE HAND BRAKE VALVE WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
VALVE HAND BRAKE VALVE WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
PLUG FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24", 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
VALVE PARKING BRAKE VALVE WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
REPAIR KITTO KNORR
