Поз.
Артикул
Описание
148
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
148
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
148
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
148
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
150
FITTING , Replaced By: A0029905971
150
FITTING (PARTS KIT),LINE RUPTURE
152
UNION NUT LINE CONNECTION
154
GLAND LINE CONNECTION
156
BANJO UNION HEATING CONNECTION,K 169122
158
FITTING , Replaced By: N915059006000
158
FITTING
160
SLEEVE , Replaced By: N915062006000
160
SLEEVE LINE CONNECTION
860
VALVE HAND BRAKE VALVE KNORR, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
860
VALVE HAND BRAKE VALVE WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
861
VALVE PARKING BRAKE VALVE BOSCH
861
VALVE PARKING BRAKE VALVE WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
861
VALVE PARKING BRAKE VALVE KNORR
862
HANDLETO BOSCH
862
HANDLETO WABCO
865
REPAIR KIT , Replaced By: A0004305760
865
REPAIR KITTO 000 430 55 81,WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
871
HOLLOW SCREW , Replaced By: N915036010108
871
HOLLOW SCREW FUEL LINE TO FEED PUMP
877
SCREW PEDAL TO CAB FLOOR
880
SHIM VALVE TO CAB, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
883
SCREW PARKING BRAKE VALVE TO WINDOW SILL
886
LOCK WASHER PARKING BRAKE VALVE TO WINDOW SILL
999
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
999
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
999
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
999
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
999
HOLLOW SCREW LINE CONNECTION
999
SEAL RING , Replaced By: N007603012121
999
HOLLOW SCREW FITTING RELAY VALVE,CONNECTION "20",LEFT
999
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
999
HOLLOW SCREW FITTING PNEUMATIC CYLINDER,CONNECTION: "10",5 308944
999
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
999
HOLLOW SCREW HEATING CONNECTION
999
UNION NUT LINE CONNECTION
999
NUT , Replaced By: N913004008001
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
NUT , Replaced By: N913004006001
999
NUT PUMP TO BRACKET
999
LOCK WASHER FITTING TO BRACKET
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
NUT STRAP TO BRACKET
999
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
999
NUT FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "22",4 821954
999
NUT
999
NUT
999
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
999
SCREW PIPE CLAMP
999
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
NUT BRACKET TO SIDE MEMBER
999
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
999
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
999
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
999
NUT CHECK VALVE TO AIR RESERVOIR
999
YOKE FOLLOWER LEVER TO CLUTCH BOOSTER
999
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
999
SCREW CLAMP TO BRACKET
999
SCREW CLAMP TO BRACKET, Replaced By: N007985006581
999
SHEET METAL SCREW BRACKET TO ELECTRICAL APPARATUS COMPARTMENT 4,8X19
999
SHEET METAL SCREW BRACKET TO CAB FLOOR
999
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
SEAL RING FUEL LINE TO FEED PUMP
999
SEAL RING LINE CONNECTION
999
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
999
T-FITTING. FITTING AT INJECTION PUMP
999
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 350368
999
BULKHEAD FITTING THROUGH SIDE MEMBER
999
CONNECTION FITTING ENGINE AIR COMPRESSOR,CONNECTION: "15"
999
CLAMPING SLEEVEKNORR
999
WASHER BEARING BRACKET TO BRACKET
999
WASHER STRAP TO SUPPORT
999
WASHER BRACKET TO FENDER BRACKET
999
PIN SHIFTING ROD TO TRANSMISSION
999
SCREW , Replaced By: N308676012012
999
NUT , Replaced By: N304035012002
999
SCREW HAND PUMP TO BRACKET
999
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SCREW , Replaced By: A0079900801
999
SCREW , Replaced By: N304017008016
999
SCREW , Replaced By: N304017008021
999
SCREW , Replaced By: N304017008039
999
SCREW LONGITUDINAL DIFFERENTIAL LOCK VALVE TO BRACKET,5 963747
999
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
999
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
999
SCREW PLUG , Replaced By: N000908012009
999
LOCK RING STEERING WHEEL HEIGHT ADJUSTMENT,4 188879
999
NUT COMPRESSED AIR LINE THRU FRAME,5 395034
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER , Replaced By: N000125008443
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
COTTER PIN STRAP TO SUPPORT
999
COTTER PIN CYLINDER TO BRACKET
999
COTTER PIN CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
999
CLAMP25-40X13 MM
999
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
999
GUIDE SIGN GUIDE SIGN,5 281205, 648.015 294702, 648.06/07
999
GUIDE SIGN , ONLY APPLICABLE TO CHASSIS 5 052758,5 054028,5 054598,5 055072,5 055390,5 055399,5 055419,5 056042,5 056076,5 056122,5 057423,5 057688,5 057923,5 058094, 5 058563,5 058579,5 058892,5 059303,5 059821,5 059846,5 059961,5 060128,5 060170,5 061184,5 062288,5 062554,5 062824,5 062889, 5 062922,5 063412,5 063495,5 063800,5 064309,5 064340,5 064498,5 064565,5 065006,5 065263,5 065805,5 065982,5 066103,5 066458, 5 066887,5 066924,5 067662,5 067959,5 068022,5 068510,5 069212.
999
GUIDE SIGN LOAD-DEPENDING BRAKE
999
ANGLE METAL SPRING BELLOWS TO REAR AXLE
999
BRACKET TRAILING AXLE CONTROL
999
BRACKET LEVER
999
BRACKET METAL SPRING BELLOWS
999
CONSOLE METAL SPRING BELLOWS
999
BRACKET PRESSURE RELIEF VALVE
999
BRACKET HOSDE TO FRAME
999
FITTING ENGINE AIR COMPRESSOR,CONNECTION: "20"
999
CLAMP BRAKE HOSE
999
COVERING CHECK VALVE,5 298639
999
STRAP AIR RESERVOIR III,5 088362
999
STRAP AIR RESERVOIR TO BRACKET
999
BRACKET , Replaced By: A6164290140
999
BRACKET FOR PASSAGE OF LINE
999
BRACKET FOR PASSAGE OF LINE
999
LOCK BRAKE HOSE TO ANGLE
999
SEAL RING TO SEAL CABLE HARNESS OPENING IN CAB
999
BRACKET , Replaced By: A6154200186
999
BRACKET RIGHT COMPRESSED AIR LINES
999
BRACKET HEAT SHIELD
999
BRACKET COMPRESSED AIR LINE TO ENGINE BEARING BRACKET
999
COVERING INTERMEDIATE BEARING
999
COVERING
999
BRACKET ELECTRIC CONTROL
999
ADHESIVE FOIL GUIDE SIGN
999
BRACKET PRESSURE GAUGE LINE TO BRACKET,4 895864
999
BRACKET BUMPER,RIGHT, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
BRACKET SWITCH
999
BUSHING INTERMEDIATE LEVER TO BEARING BRACKET,5 943507
999
COVERING , Replaced By: A6153010088
999
COVERING , Replaced By: A4073015088
999
SCREW BRACKET
999
WASHER BRACKET TO LEFT SIDE MEMBER
999
WASHER BRACKET TO CROSS MEMBER,5 434013
999
CLAMP BRAKE HOSE
999
SEAL RINGTO 000 429 27 95, WABCO
999
SEAL RING
999
SEAL RINGTO 000 429 25 95,BOSCH
999
SEAL RINGKNORR
999
SEAL RING15.3X2.4 MM,TO 003 429 12 44,SCHAEFER
999
SEAL RING13.6X2 MM,TO 003 429 12 44,SCHAEFER
999
SEAL RINGKNORR
999
SEAL RINGKNORR
999
SEAL RINGKNORR
999
SEAL RINGKNORR
999
SEAL RING
999
SEAL RING56X1.7 MM
999
SEAL RING28.4X2.6 MM
999
SEAL RINGTO 000 429 28 95,GRAU
999
SEAL RING19.3X2.4 MM,TO 003 429 04 44,WABCO
999
SEAL RING34.6X2.6 MM
999
SEAL RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
999
SCREW REDUCTION VALVE TO BRACKET
999
FITTING SHUTTLE VALVE,CONNECTION: "20",5 434013
999
SEAL RINGTO 001 431 43 05,002 431 05 05
999
SEAL RINGTO 001 431 43 05,002 431 05 05
999
SEAL RINGTO 001 431 43 05,002 431 05 05
999
SEAL RINGTO 000 429 28 95,GRAU
999
SEAL RING22.3X2.4 MM,GRAU
999
SPRINGTO 000 429 27 95,WABCO
999
FITTING 3/2-WAY VALVE,CONNECTION: "20"
999
FITTING
999
GROMMET AT SIDE MEMBER,5 314333
999
REPAIR KITTO 001 430 66 81,001 430 67 81,KNORR
999
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) WABCO
999
REPAIR KITTO 000 430 66 81,000 430 67 81, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
REPAIR KITTO 001 430 56 81,001 430 57 81
999
GASKET KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,000 2
999
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
VALVE (CHECK VALVE) SCHAEFER
999
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
999
FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
FITTING DELIVERY LINE TO PUMP
999
ELBOW FITTING ,5 433281
999
ELBOW FITTING HOSE WIDTH, 9 MM,TO M 22
999
ELBOW FITTING ,5 181111 10/50 616.121,122,131,1325 208196 20/60 616.121,122,131,1325 297633 616.024,026,027,028,065
999
ELBOW FITTING ,5 181111 10/50 616.121,122,131,1325 208196 20/60 616.121,122,131,1325 297633 616.024,026,027,028,065
999
REPAIR KITTO 001 431 12 06, KNORR 3200
999
REPAIR KIT , Replaced By: A0034303881
999
REPAIR KITGRAU,5 148812
999
REPAIR KIT SLAVE CYLINDER TO 006 420 15 18
999
REPAIR KIT SLAVE CYLINDER TO 006 420 15 18, UP TO SCHAEFER CHARACTERISTIC NO.489
999
VALVE , Replaced By: A0034315006
999
PRESSURE REGULATORKNORR,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
VALVE PARKING BRAKE VALVE KNORR
999
REPAIR KIT VALVE KIT WABCO,5 148812
999
VALVE (CHECK VALVE) VOSS
999
VALVE (OVERFLOW VALVE),4 9119185 116581
999
VALVE (CHECK VALVE)
999
VALVE , Replaced By: A0034295344
999
FITTING HOSE TO BRACKET
