Поз.
Артикул
Описание
154
TEST CONNECTION
154
TEST CONNECTION
154
TEST CONNECTION
154
TEST CONNECTION
154
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
154
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
154
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
154
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
154
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
154
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
154
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
154
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
154
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
154
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
154
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
154
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
370
BRACKET RELAY VALVE TO CROSS MEMBER
373
NUT , Replaced By: N913004008001
373
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
376
SCREW , Replaced By: N304017008021
376
SCREW PIPE CLAMP
379
NUT , Replaced By: N913004008001
379
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
382
SCREW , Replaced By: N304017008034
382
SCREW BRACKET TO CROSS CONNECTION STRUT
430
WASHER , Replaced By: N000125008443
430
WASHER EXHAUST MUFFLER TO STRAP
433
BRACKET BRAKE POWER REGULATOR TO CROSS MEMBER
439
NUT , Replaced By: N913004008001
439
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
442
SCREW , Replaced By: N304017008021
442
SCREW PIPE CLAMP
448
NUT , Replaced By: N913004008001
448
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
469
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
472
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
475
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
478
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
478
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
481
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
481
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
484
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
484
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
487
HOLLOW SCREW LINE CONNECTION
490
SEAL RING LINE CONNECTION
493
HOLLOW SCREW FITTING RELAY VALVE,CONNECTION "20",LEFT
493
HOLLOW SCREW FITTING RELAY VALVE,CONNECTION "20",LEFT
496
SWITCH SUPPLY PRESSURE,5 966147
999
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
999
HOLLOW SCREW FITTING DIAPHRAGM CYLINDER,CONNECTION: "12"
999
HOLLOW SCREW HEATING CONNECTION
999
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
999
SEAL RING LINE CONNECTION
999
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SCREW , Replaced By: A4609900601
999
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
999
SCREW PLUG , Replaced By: N000908022011
999
STRAP PARTICLE FILTER
999
STRAP , Replaced By: A6554900942
999
STRAP , Replaced By: A6214900242
999
STRAP SPRING-LOADED BRAKE AIR RESERVOIR, Replaced By: A6554900942
999
BRACKET SPRING-LOADED BRAKE AIR RESERVOIR
999
SCREW EXHAUST PIPE TO BRACKET
999
SEAL RINGWABCO
999
SEAL RINGTO 000 434 23 01
999
SEAL RINGTO 000 434 23 01
999
SEAL RINGTO 000 434 21 01
999
REPAIR KIT 3/2-WAY VALVE WABCO
999
REPAIR KIT 3/2-WAY VALVE BOSCH
999
T-FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
999
REPAIR KITBOSCH
999
SPRINGTO 000 434 21 01
999
GASKET KITKNORR
999
PLUG
999
COUPLING FROM CHECK VALVE TO PARKING BRAKE VALVE
999
HANDLETO 000 434 23 01
999
VALVE EXHAUST BRAKE OPERATING MECHANISM WESTINGHOUSE
999
VALVE EXHAUST BRAKE OPERATING MECHANISM BOSCH
999
CUP 3/2-WAY VALVE WABCO
999
STRAINERTO 000 434 21 01
999
AIR CLEANER COMPLETE TO BOSCH,KNORR
999
AIR CLEANER COMPLETE KNECHT:TO BOSCH,KNORR
