Поз.
Артикул
Описание
22
RADIATOR CAP CENTRAL
22
RADIATOR CAP CENTRAL
27
RADIATOR CAP FILLER NECK
27
RADIATOR CAP FILLER NECK
28
SCREW PLUG WATER DRAIN
28
SCREW PLUG , Replaced By: N007604014101
30
SEAL RING FUEL LINE TO FEED PUMP
32
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
32
SCREW , Replaced By: N304017008016
37
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
42
WASHER , Replaced By: N000125008443
42
WASHER EXHAUST MUFFLER TO STRAP
47
HOSE OVERFLOW, EXPANSION TANK
52
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
52
CLAMP , Replaced By: N916017011000
52
CLAMP , Replaced By: N916017011001
87
NUT SUPPORT TO SIDE MEMBER
102
SPRING WASHER STEERING COLUMN BRACKET TO CAB
107
RUBBER MOUNTING RADIATOR
107
RUBBER MOUNTING , Replaced By: A6205040112
112
SCREW , Replaced By: N304017010028
112
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
117
SPRING WASHER STEERING COLUMN BRACKET TO CAB
122
SCREW END PIECE TO EXHAUST PIPE M 10X25
132
SPRING WASHER STEERING COLUMN BRACKET TO CAB
137
FAN SHROUD RADIATOR
142
CLIP-TYPE NUT FAN SHROUD TO RADIATOR
147
BOOT FAN SHROUD TO FAN RING
317
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 60-80X13 MM
317
CLAMP , Replaced By: N000000000674
999
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
999
HOSE , Replaced By: A0149975782
999
HOSE , Replaced By: A0139978682
999
SCREW EXHAUST PIPE TO BRACKET
999
BREATHER PIPE , Replaced By: A6205010725
999
FLANGE
999
HOSE FROM VALVE TO FEED LINE,K 004003
999
BRACKET HEATING PIPE
999
HOSE HEATING PIPE TO RADIATOR
999
SPRING WASHER , Replaced By: N000137008212
999
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SCREW , Replaced By: N000933008337
999
SCREW , Replaced By: N304017008018
999
SCREW , Replaced By: A4609900601
999
SCREW , Replaced By: A0099900101
999
SCREW SUPPORT TO FENDER
999
HOSE FROM BUBBLE SEPARATOR TO HEATING PIPE 18X27 MM, ORDER BY THE METER
999
NUT STRAP TO BRACKET
999
GASKET HEATING PIPE TO ENGINE
