Поз.
Артикул
Описание
5
PLASTIC PIPE8X6 MM, ORDER BY THE METER
8
PLASTIC PIPE4X6 MM, ORDER BY THE METER
13
13
13
14
14
14
15
ELBOW FITTING SINGLE CIRCUIT PISTON CYLINDER, CONNECTION:
15
FITTING , Replaced By: A0019909871
17
UNION NUT
17
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M16 ,VOSS 232
20
UNION NUT LINE CONNECTION
23
GLAND , Replaced By: A0019901667
26
GLAND LINE CONNECTION
29
SLEEVE LEAK LINE
29
SLEEVE LINE CONNECTION
33
COUPLING "TOP-BRAKE"
35
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
38
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION TO M16, 9MM, VOSS 232
38
CONNECTION PIECE COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16, 4 MM, Replaced By: A0059977889
41
CONNECTOR HOSE WIDTH, 9 MM,TO M 22
41
CONNECTION PIECE COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22, 9 MM, VOSS 232
44
CONNECTOR , Replaced By: A0029905478
47
CONNECTION PIECE COMPRESSED-AIR-LINE PLUG-CONNECTION TO M16, 6MM, VOSS 232, Replaced By: A0049976989
47
CONNECTION PIECE COMPRESSED-AIR-LINE PLUG-CONNECTION TO M22, 6MM, VOSS 232
50
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22, 6 MM, VOSS 232
50
ELBOW FITTINGTO M10 / 4MM /VOSS 230
50
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22, 9 MM, VOSS 232
50
ELBOW FITTING CONNECTION OF COMPRESSED AIR LINES TO M 16 / 4 MM ,VOSS 232,KAN 33/00 AS OF PRODUCTION BREAKPOINT DATE 01.01.2004
50
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16, 6 MM, VOSS 232, Replaced By: A0059972689
53
ELBOW FITTING , Replaced By: A0049971389
53
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
56
COUPLING6MM,D 283510
59
COUPLING LINE CONNECTIONS 12X1.5
63
PLUG COMPRESSED AIR PIPING,YB227219
64
COUPLING COMPRESSED AIR PIPING,YB227219
65
INSULATING HOSE RED, ORDER BY THE METER
65
INSULATING HOSE8X0,01 MM
65
INSULATING HOSE
65
INSULATING HOSE CHECK VALVE,CONNECTION "2"
65
INSULATING HOSE COLOR CODE BLUE,YB227219
65
INSULATING HOSE COLOR CODE ORANGE 12X0.8 MM, ORDER BY THE METER
65
INSULATING HOSE RED, ORDER BY THE METER
65
INSULATING HOSE COLOR CODE GREY,YB227219
65
INSULATING HOSE , ORDER BY THE METER
68
LOOM TIE WIRING HARNESS FOR AIR CONDITIONING SYSTEM 205 MM
68
LOOM TIE ELECTRIC CABLE MOUNTING
68
LOOM TIE AIR INTAKE HOSE TO CLAMP
71
SWITCH PARKING BRAKE VALVE,CONNECTION: "11"
75
ADAPTER FITTING TEST CONNECTION
77
ADAPTER FITTING TEST CONNECTION
999
ADAPTER FITTING CENTRAL AND REAR AXLES
