Поз.
Артикул
Описание
463
PLATE , Replaced By: A6203310026
463
PLATE FRONT SPRINGS TO FRONT AXLE
466
RUBBER BUFFER SPRING STOP
467
PIN FRONT SPRINGS TO FRONT AXLE 28 MM, Replaced By: A9303230374
467
PIN , Replaced By: A6573310074
467
CENTERING BOLT FRONT SPRINGS TO FRONT AXLE 28 MM
469
U-BOLT FRONT SPRINGS TO FRONT AXLE 212 MM,5 0251885 184732
469
U-BOLT FRONT SPRINGS TO FRONT AXLE 275 MM
471
NUT , Replaced By: N308674020000
471
NUT REAR SPRING TO REAR AXLE
471
NUT , Replaced By: N308673020002
476
BEARING BRACKET LEFT, TO BE ADAPTED DURING ASSEMBLY
483
SHACKLE TORSION BAR,FRONT,5 165467
485
SCREW , Replaced By: N304017008018
485
SCREW SUPPORT TO FENDER
488
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
493
TORSION BAR FRONT,5 184731
495
RUBBER MOUNTING TORSION BAR,5 184731
497
BEARING TORSION BAR,SHOCK ABSORBER,RIGHT,5 0636025 184731
497
BEARING TORSION BAR,SHOCK ABSORBER,LEFT,5 0636025 184731
499
LOCK RING SHACKLE TO TORSION BAR,5 904660
507
SPACER WASHER LINK TO CONSOLE
508
SPACER WASHER SHACKLE TO BEARING BRACKET,5 904660
511
BUSHING SHACKLE TO BEARING BRACKET,5 904660
513
NUT COMBINATION CYLINDER TO BEARING BRACKET
513
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
514
SPACER WASHER LINK TO CONSOLE
517
PIN TORSION BAR TO SHACKLE
520
BUSHING TORSION BAR TO BEARING BRACKET,5 184731
522
LOCK RING SHACKLE TO CONSOLE TO 393 326 00 63,965965
523
WASHER BRACKET TO SPARE WHEEL CARRIER
524
NUT INTERMEDIATE LEVER TO STEERING SUPPORT
524
NUT , Replaced By: N910113018004
528
SCREW BRACKET TO TORSION BAR,4 9511495 554754
529
NUT , Replaced By: N910113010002
529
HEXAGON NUT
530
BRACKET TORSION BAR,4 9511495 554754
530
BRACKET TORSION BAR,5 554754
999
PIN TORSION BAR TO BEARING BRACKET
999
REPAIR KIT TORSION BAR TO REAR AXLE
999
SPACER WASHER AS REQUIRED 1.00 MM
999
SPACER WASHER AS REQUIRED 4.00 MM
