Поз.
Артикул
Описание
4
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
4
HOSE , Replaced By: A0009872827
8
FITTING (PARTS KIT),LINE RUPTURE
8
FITTING , Replaced By: A0029906171
12
UNION NUT LINE CONNECTION
12
UNION NUT LINE CONNECTION, Replaced By: N000000006239
16
SEAL CONE LINE CONNECTION
16
GLAND , Replaced By: A0019901967
20
SLEEVE LINE CONNECTION
24
ELBOW FITTING 3/2-WAY VALVE BREATHING
28
PLUG 3/2-WAY VALVE BREATHING
36
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
40
FITTING (PARTS KIT),LINE RUPTURE
40
FITTING , Replaced By: A0029905971
44
UNION NUT LINE CONNECTION
48
GLAND LINE CONNECTION
52
SLEEVE LINE CONNECTION
56
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
56
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
60
FITTING BETWEEN THE LINES
64
PLASTIC PIPE RISING PIPE 4X6 MM
64
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
68
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
72
UNION NUT
76
SEAL CONE
76
GLAND , Replaced By: A0019901667
80
SLEEVE LEAK LINE
84
BANJO UNION HOSE WIDTH, / I.D., 4/16 MM
84
BANJO UNION HOSE WIDTH, / I.D., 4/14 MM,K 169123
84
BANJO UNION , Replaced By: N000000000364
84
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
96
LOOM TIE LINE MOUNTING
96
LOOM TIE LINE MOUNTING 280 MM
100
VALVE (3/2-WAY SOLENOID VALVE) WABCO
104
SEAL RINGWABCO
108
SEAL RINGWABCO
112
SEAL RINGWABCO
116
VALVE PARTWABCO
120
HOLLOW SCREW HEATING CONNECTION
124
SEAL RING LINE CONNECTION
128
BRACKET 3/2-WAY VALVE, NOT USED
136
SCREW VALVE TO BRACKET M 8X55
136
SCREW , Replaced By: N304017008043
140
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
140
NUT , Replaced By: N913004008001
144
REINFORCEMENT DISTRIBUTOR TO CAB
148
SCREW PUMP TO BRACKET
148
SCREW , Replaced By: N304017006016
152
NUT PUMP TO BRACKET
152
NUT , Replaced By: N913004006001
164
VALVE SHUTTLE VALVE, REPAIR IMPOSSIBLE
164
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 313530, Replaced By: A0012604957
172
FITTING LINE CONNECTION
176
SEAL RING FUEL LINE TO FEED PUMP
180
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
184
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
184
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
188
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
192
HOLLOW SCREW FUEL LINE TO FEED PUMP
192
HOLLOW SCREW , Replaced By: N915036010108
196
SEAL RING FUEL LINE TO FEED PUMP
300
T-FITTING EXTENSIBLE BRAKE VALVE, 4 691696
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
O-RING CHECK VALVE TO AIR RESERVOIR
999
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
999
THRUST RING CHECK VALVE TO AIR RESERVOIR
999
BANJO UNION AT AIR RESERVOIR,4 484801
999
T-FITTING EXHAUST BRAKE 3/2-WAY VALVE
999
ELBOW FITTING RELAY VALVE,CONNECTIONS: "21,22"
999
FITTING DELIVERY LINE TO PUMP
999
FITTING 3/2-WAY VALVE
999
GASKET KITKNORR
999
FITTING RELAY VALVE,CONNECTION "20",LEFT
999
SEAL RINGBOSCH
999
GUIDE BUSHING TWO-WAY VALVE TO FRAME
999
SPACER TUBE , Replaced By: A3094310249
999
LINE FROM BRAKE POWER REGULATOR TO 2/2-WAY VALVE, NOT USED
999
BRACKET 3/2-WAY VALVE,5 328806
999
BRACKET SOLENOID VALVE,5 347349
999
WASHER , Replaced By: N000125010532
999
WASHER RADIATOR TO RUBBER MOUNTING
999
SCREW BRACKET TO EXHAUST PIPE,5 528482
999
SCREW CONTROL VALVE
999
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SEAL RINGBOSCH
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
NUT STRAP TO BRACKET
999
NUT , Replaced By: N910113010000
999
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
