Поз.
Артикул
Описание
14
SCREW CONNECTOR TO EXHAUST MANIFOLD
17
NUT CONNECTOR TO EXHAUST MANIFOLD
35
FLEXIBLE METAL TUBE CONNECTOR
38
COLLAR EXHAUST LINE FLEXIBLE METAL TUBE
41
CLAMP FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
44
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
44
SCREW , Replaced By: N304017008027
47
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
47
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
47
NUT , Replaced By: N913004008001
59
BRACKET RIGHT, TO BE ADAPTED DURING ASSEMBLY
59
BRACKET LEFT
68
CLAMP FLEXIBLE METAL TUBE TO EXHAUST PIPE
71
SCREW BRACKET TO SIDE MEMBER
71
SCREW , Replaced By: N304017010002
77
NUT STRAP TO BRACKET
77
NUT , Replaced By: N910113010000
83
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
86
SCREW BRACKET TO SIDE MEMBER
86
SCREW , Replaced By: N304017010002
89
NUT STRAP TO BRACKET
89
NUT , Replaced By: N910113010000
