Поз.
Артикул
Описание
8
FENDER ,5 005872
11
BRACKET FRONT FENDER
11
BRACKET REAR FENDER
11
BRACKET FENDER TO BRACKET
14
CLAMPING PIECE
14
CLAMPING PIECE
17
RIVET9X48 MM
17
RIVET
20
EYEBOLT
20
SCREW
23
NUT
26
REINFORCEMENT FENDER
26
REINFORCEMENT FRONT FENDER
26
REINFORCEMENT REAR FENDER
26
REINFORCEMENT FENDER FIXTURE 505 MM
26
REINFORCEMENT FENDER
29
SCREW BRACKET TO REAR FENDER
32
NUT BALL PIVOT TO LEVER
35
SCREW CLAMP MOUNTING M 6X16
35
SCREW , Replaced By: N000000001146
37
WASHER , Replaced By: N009021006208
37
WASHER COMPRESSED AIR LINE TO BRACKET
39
NUT PUMP TO BRACKET
39
NUT , Replaced By: N913004006001
41
BEARING BRACKET , 393.311 UP TO CHASSIS 4 450302,393.321 UP TO CHASSIS 4 453 074,395.312,322,412,422 UP TO CHASSIS 4 426005
43
BEARING BRACKET TAIL LAMP, FOR USE WITH SHORT MERCEDES-BENZ CAB
45
SCREW REAR EXHAUST PIPE TO MUFFLER
47
NUT , Replaced By: N910113010000
47
NUT STRAP TO BRACKET
50
BRACKET LEFT REAR
50
BRACKET TAIL LAMP
50
BRACKET RIGHT TAIL LAMP, UP TO IDENT NO. K 279038, FROM IDENT NO. SEE STANDARD VERSION
50
BRACKET FENDER TO BEARING BRACKET, FRONT,K 103913 TO BE ADAPTED DURING ASSEMBLY
50
BRACKET LEFT AND RIGHT FRONT
50
BRACKET RIGHT REAR
50
BRACKET LEFT REAR
50
BRACKET LEFT REAR
50
BRACKET TAIL LAMP
50
BRACKET RIGHT REAR
50
BRACKET RIGHT REAR
50
BRACKET FENDER TO BEARING BRACKET, FRONT, TO BE ADAPTED DURING ASSEMBLY
52
BRACKET LEFT FRONT FENDER
52
BRACKET RIGHT FRONT FENDER
52
BRACKET LEFT FRONT FENDER
52
BRACKET RIGHT FRONT FENDER
52
BRACKET LEFT FRONT FENDER
52
BRACKET RIGHT FRONT FENDER
54
BRACKET REAR FENDER
54
BRACKET REAR FENDER
56
EXPANSION PLUG BRACKET
58
SCREW MOUNTING AND RAIL TO LEAF SPRING
58
SCREW REAR EXHAUST PIPE TO MUFFLER
60
NUT , Replaced By: N910113010000
60
NUT STRAP TO BRACKET
62
SCREW , Replaced By: N304017010050
62
SCREW , Replaced By: N304017010055
62
SCREW REAR AXLE REGULATING SOLENOID VALVE
64
NUT , Replaced By: N910113010000
64
NUT , Replaced By: N913004008001
64
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
64
NUT STRAP TO BRACKET
66
ANTINOISE CAPSULE REAR WHEELS
66
ANTINOISE CAPSULE REAR WHEELS
66
ANTINOISE CAPSULE REAR WHEELS
66
ANTINOISE CAPSULE REAR WHEELS
68
BINDING RAIL COVERING
71
RIVET BINDING RAIL TO COVERING
74
BRACKET COVERING
77
RIVET BRACKET TO BINDING RAIL
80
WASHER COMPRESSED AIR LINE TO BRACKET
80
WASHER , Replaced By: N009021006208
83
BRACKET COVERING TO FRONT AND REAR BRACKETS
86
BRACKET
89
COVERING BRACKET TO COVERING
92
LEDGE
96
SCREW PUMP TO BRACKET
96
SCREW , Replaced By: N304017006016
100
SCREW DELIVERY AND SUCTION HOSES TO COUPLING MOUTH CROSS MEMBER,5 598039
104
COMBINATION BOLT BRACKET TO COVERING
108
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
112
NUT PUMP TO BRACKET
112
NUT , Replaced By: N913004006001
116
BRACKET COVERING TO FRONT FENDER
120
SCREW LONGITUDINAL DIFFERENTIAL LOCK VALVE TO BRACKET,5 963747
120
SCREW CAB FLOOR COVERING M 6X25
124
WASHER COMPRESSED AIR LINE TO BRACKET
124
WASHER , Replaced By: N009021006208
128
NUT PUMP TO BRACKET
128
NUT , Replaced By: N913004006001
132
PIN COVERING AND PIN TO FENDER HALF SHELL
136
SCREW , Replaced By: A0029903712
136
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
136
SCREW , Replaced By: N000000001149
140
NUT , Replaced By: N913004006001
140
NUT PUMP TO BRACKET
