Поз.
Артикул
Описание
5
VALVE PARKING BRAKE WITH TRAILER CONTROL "WABCO", PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
VALVE PARKING BRAKE WITH TRAILER CONTROL "BOSCH"
5
VALVE PARKING BRAKE WITH TRAILER CONTROL "KNORR"
8
HANDLETO 002 430 93 81
11
BUSHINGTO 002 430 93 81
11
BUSHING"WABCO"
11
BUSHING , Replaced By: A4421440050
14
PROTECTIVE CAP PARKING BRAKE VALVE WABCO
14
PROTECTIVE CAPTO 002 430 93 81
17
LEVERTO 002 430 93 81
17
LEVER PARKING BRAKE VALVE WABCO
20
SPRING RETAINERTO 002 430 93 81
23
PINTO 002 430 93 81
23
PINTO 002 430 90 81
26
REPAIR KIT HAND BRAKE VALVE "WABCO"
26
REPAIR KITBOSCH,TO 002 430 93 81
29
SCREW PARKING BRAKE VALVE TO WINDOW SILL
32
LOCK WASHER PARKING BRAKE VALVE TO WINDOW SILL
35
GUMMED LABEL PARKING BRAKE ACTUATION
38
BREATHER PIPE PARKING BRAKE VALVE,CONNECTION: "30"
38
BREATHER PIPE PARKING BRAKE VALVE,CONNECTION: "30", Replaced By: A6554310273
41
SCREW. UNION SCREW , Replaced By: A0009973734
41
SCREW. UNION SCREW LINE CONNECTION
42
CLAMP HOSE TO PARKING BRAKE VALVE
44
BRAKE VALVE (TRAILER CONTROL VALVE) "GRAU", PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
44
TRAILER CONTROL VALVE (TRAILER CONTROL VALVE) "KNORR"
44
BRAKE VALVE (TRAILER CONTROL VALVE) "WABCO", PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
44
BRAKE VALVE (TRAILER CONTROL VALVE) "BOSCH"
44
BRAKE VALVE , Replaced By: A0034318205
47
REPAIR KIT TRAILER CONTROL VALVE "GRAU"
47
REPAIR KIT TRAILER CONTROL VALVE "WABCO"
50
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
50
NUT , Replaced By: N913004008001
53
BRACKET TRAILER CONTROL VALVE
56
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
56
SCREW , Replaced By: N304017008027
59
NUT , Replaced By: N913004008001
59
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
62
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
65
SCREW. UNION SCREW LINE CONNECTION
68
SCREW. UNION SCREW LINE CONNECTION
68
SCREW. UNION SCREW , Replaced By: A0009973734
71
SUPPORT TWO-CIRCUIT BRAKE LINE COUPLING
74
ANGLE SUPPORT,RIGHT
74
ANGLE SUPPORT,LEFT
77
SCREW PIPE CLAMP
77
SCREW , Replaced By: N304017008021
77
SCREW , Replaced By: N304017008034
77
SCREW BRACKET TO CROSS CONNECTION STRUT
80
WASHER , Replaced By: N000125008443
80
WASHER EXHAUST MUFFLER TO STRAP
83
NUT , Replaced By: N913004008001
83
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
85
SCREW , Replaced By: N308676014020
85
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
85
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
88
NUT , Replaced By: N910113014001
88
NUT BRACKET TO SIDE MEMBER
91
ADAPTER FITTING LINE CONNECTION TO ENGINE
92
ELBOW FITTING CONNECTION OF COMPRESSED AIR LINE 9 MM, M 18X1.5,K 168170
93
ELBOW FITTING CONNECTION OF COMPRESSED AIR LINE 9 MM, M 18X1.5,K 168170
94
NUT BRACKET TO SIDE MEMBER
97
SCREW. UNION SCREW LINE CONNECTION
999
HANDLE"WABCO"
