Поз.
Артикул
Описание
5
HOSE , Replaced By: A0009872827
5
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
10
FITTING , Replaced By: A0029906171
10
FITTING (PARTS KIT),LINE RUPTURE
15
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
20
FITTING , Replaced By: A0029905971
20
FITTING (PARTS KIT),LINE RUPTURE
25
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
30
ELBOW FITTING , Replaced By: A0049905371
30
ELBOW FITTING HOSE WIDTH, 9 MM,TO M22
30
ELBOW FITTING HOSE WIDTH, 6 MM,TO M22
32
ELBOW FITTING HOSE WIDTH, 9 MM,TO M 22
33
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
33
T-FITTING , Replaced By: A0059903370
35
CONNECTOR , Replaced By: A0029905478
35
CONNECTOR HOSE WIDTH, 6 MM,TO M16
35
CONNECTOR HOSE WIDTH, 9 MM,TO M 22
39
CONNECTOR , Replaced By: A0029905478
39
CONNECTOR HOSE WIDTH, 6 MM,TO M16
40
CONNECTOR HOSE WIDTH, 9 MM,TO M 22
40
CONNECTOR HOSE WIDTH, 6 MM, TO M22
42
CONNECTOR DISTRIBUTOR TO CAB
43
SEAL RING
44
CONNECTOR HOSE WIDTH, / I.D., 6 MM
45
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
47
DISTRIBUTOR
50
SCREW. UNION SCREW LINE CONNECTION
50
SCREW. UNION SCREW LINE CONNECTION
50
SCREW. UNION SCREW , Replaced By: A0009973734
55
LOCK LINE CONNECTION
55
LOCK , Replaced By: A0009945448
55
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
65
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
65
LOCK RING LINE CONNECTION
65
SEAL RING , Replaced By: A0009940747
75
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
75
REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
75
REPAIR KIT , Replaced By: A0309971748
78
WASHER BRACKET TO LEFT SIDE MEMBER
82
FITTING LINE CONNECTION
83
BRACKET COMPRESSED AIR LINES,K 168169
83
BRACKET , Replaced By: A3464310440
84
SCREW BRACKET TO SIDE MEMBER,K 168169
84
SCREW , Replaced By: A0089907401
85
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
85
NUT , Replaced By: N913004008001
86
LOOM TIE LINE MOUNTING 280 MM
86
LOOM TIE LINE MOUNTING
87
SCREW. UNION SCREW , Replaced By: A0009973734
87
SCREW. UNION SCREW LINE CONNECTION
150
BRAKE LINE COUPLING SUPPLY, RED "KNORR"
150
BRAKE LINE COUPLING , Replaced By: A0004299730
150
BRAKE LINE COUPLING BRAKE,YELLOW "BOSCH"
150
BRAKE LINE COUPLING SUPPLY, RED "BOSCH"
150
BRAKE LINE COUPLING SUPPLY, RED "WABCO"
150
BRAKE LINE COUPLING , Replaced By: A0004299630
150
BRAKE LINE COUPLING BRAKE,YELLOW "KNORR"
150
BRAKE LINE COUPLING BRAKE,YELLOW "GRAU"
150
BRAKE LINE COUPLING BRAKE,YELLOW "WABCO"
150
BRAKE LINE COUPLING SUPPLY, RED "GRAU"
152
SEAL RING30X2 MM,BOSCH
154
SEAL RING25X2 MM,BOSCH
156
SEAL RING33X2.5 MM,BOSCH
160
SEAL RING , Replaced By: A0049978240, +001A0004290483
160
SEAL RING22X4 MM,BOSCH
160
VALVE TAPPET22X4 MM,BOSCH
165
SEAL RING"GRAU"
170
COVER SUPPLY, RED "WABCO"
170
COVER BRAKE,YELLOW "WABCO"
175
REPAIR KIT BRAKE LINE COUPLING "KNORR"
175
REPAIR KIT BRAKE LINE COUPLING "WABCO"
180
BRACKET BRAKE LINE COUPLING,"BRAKE",K 119510 FROM IDENT NO.,SEE SPECIAL VERSION 46347, 46753, 46756
182
BRACKET LEFT BRAKE LINE COUPLING,5 561192
182
BRACKET LEFT BRAKE LINE COUPLING,5 561191
184
BRACKET RIGHT BRAKE LINE COUPLING,5 561192
184
BRACKET RIGHT BRAKE LINE COUPLING,5 561191
188
SCREW , Replaced By: N304017008034
188
SCREW BRACKET TO CROSS CONNECTION STRUT
190
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
190
NUT , Replaced By: N913004008001
195
FITTING LOAD/NO-LOAD VALVE,CONNECTION: "40",5 509133
200
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
205
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
210
WASHER , Replaced By: A3609902340
210
WASHER BRACKET TO LEFT SIDE MEMBER
215
WASHER , Replaced By: N009021008213
215
WASHER BRACKET TO LEFT SIDE MEMBER
999
SCREW CABLE HARNESS MOUNTING
999
SCREW , Replaced By: N304017008023
999
BRACKET CABLE HARNESS MOUNTING
999
BRACKET COMPRESSED AIR PIPING
999
BRACKET COMPRESSED AIR PIPING
999
BRACKET COMPRESSED AIR LINES
999
BRACKET TRAILER CONTROL VALVE,K 213086
999
BRAKE VALVE (TRAILER CONTROL VALVE) "BOSCH"
999
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
999
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
999
PROTECTIVE CAP PARKING BRAKE VALVE WABCO
999
HANDLE"WABCO"
999
CONNECTOR , Replaced By: A0029905378
999
INSULATING HOSE LENGTH AVAILABLE: 370 MM
999
LEVER PARKING BRAKE VALVE WABCO
