Поз.
Артикул
Описание
5
FUEL TANK ,K 169122, Replaced By: A6534700201, +001A0005409917, +001A0115426117
5
FUEL TANK210 L,K 169123
17
FILLER CAP , Replaced By: A0004700305
17
FILLER CAP
20
SEAL RING
23
CHAIN FILLER CAP
26
FILLER CAP LESS BREATHING
26
FILLER CAP LESS BREATHING
29
SEAL RING
32
KEYTO 000 471 67 30, STATE LOCK NUMBER WHEN ORDERING
35
SCREW PLUG , Replaced By: N007604014110
35
SCREW PLUG FUEL TANK
38
SEAL RING FUEL LINE TO FEED PUMP
41
PROTECTIVE RAIL FUEL TANK TO CONSOLE,5 429713
46
STOP SUPPORTING RAIL
48
SCREW , Replaced By: N304017008034
48
SCREW BRACKET TO CROSS CONNECTION STRUT
50
NUT , Replaced By: N913004008001
50
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
50
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
54
SUPPORT FUEL TANK,FRONT AND REAR
56
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
62
WASHER SPARE WHEEL CARRIER
65
PAD FUEL TANK SUPPORT 72 / 80, ORDER BY THE METER
66
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
68
STRAP FUEL TANK TO SUPPORT
71
NUT STRAP TO SUPPORT
71
NUT STRAP TO CONSOLE
74
WASHER
86
SENDER UNIT FUEL GAUGE,K 169123
86
SENDER UNIT ,K 169122, Replaced By: A0085426917, +001A3529870045
89
PLUG TO SEAL AUXILIARY HEATER CONNECTION 8 MM,K 169123
92
FUEL STRAINER FUEL TANK,K 169123
92
FUEL STRAINER FUEL TANK,K 169122
95
SEAL RING FUEL GAUGE SENDER UNIT TO FUEL TANK
98
CONNECTOR FEED LINE AND RETURN LINE 8X1 MM
98
CONNECTOR FEED LINE AND RETURN LINE 11X1,5 MM
98
CONNECTOR FEED LINE AND RETURN LINE 12,5X1,25 MM
101
GASKET KIT CONNECTION ON FUEL GAUGE SENSOR
104
LOCK FUEL GAUGE SENDER UNIT CONNECTION
