Поз.
Артикул
Описание
466
SCREW CONNECTION OIL LINES
474
FITTING OIL LINE TO OIL COOLER
482
SEAL RING POWER STEERING PUMP TO BEARING FLANGE
490
SCREW CONNECTION P.T.O.
498
T-FITTING P.T.O.
506
PIPE FROM OIL FILTER TO TRANSMISSION
506
LINE FROM OIL FILTER TO TRANSMISSION
514
PIPE TRANSMISSION OIL COOLER
514
PIPE TRANSMISSION OIL COOLER
514
PIPE HEAT EXCHANGER
514
PIPE (OIL LINE),FROM TRANSMISSION TO FILTER
514
PIPE FROM OIL FILTER TO TRANSMISSION
514
PIPE FROM OIL FILTER TO TRANSMISSION
514
PIPE FROM OIL FILTER TO TRANSMISSION
514
PIPE HEAT EXCHANGER
514
PIPE SOCKET FROM OIL FILTER TO TRANSMISSION
514
PIPE SOCKET FROM OIL FILTER TO TRANSMISSION
514
PIPE FROM OIL FILTER TO TRANSMISSION
522
PIPE FROM OIL FILTER TO TRANSMISSION
522
PIPE FROM OIL FILTER TO TRANSMISSION
530
GLAND LINE CONNECTION
530
SEAL CONE LINE CONNECTION M 28
538
UNION NUT LINE CONNECTION
538
NUT LINE CONNECTION M 28
538
UNION NUT , Replaced By: A0019901354
546
HOSE OIL LINE TO OIL LINE, ORDER BY THE METER
554
FITTING LINE CONNECTION
586
FLANGE OIL LINE TO HEAT EXCHANGER
586
LINE HEAT EXCHANGER
586
LINE HEAT EXCHANGER
594
CONNECTION FITTING OIL LINE CONNECTION TO OIL COOLER
602
GASKET COVER TO OIL COOLER
602
GASKET , Replaced By: A6252570580
618
LINE HEAT EXCHANGER
618
LINE HEAT EXCHANGER
626
PIPE TRANSMISSION OIL COOLER
634
PIPE SOCKET FROM OIL FILTER TO TRANSMISSION
634
PIPE SOCKET FROM OIL FILTER TO TRANSMISSION
634
FITTING HEAT EXCHANGER
642
PIPE TO P.T.O.
658
LINE FEED AND RETURN LINES TO TRANSMISSION
666
LINE FEED LINE TO RETARDER
666
LINE FEED LINE TO RETARDER
690
HOLLOW SCREW LINE CONNECTION
690
HOLLOW SCREW HEATING CONNECTION
690
HOLLOW SCREW HEATING CONNECTION
690
HOLLOW SCREW LINE CONNECTION
698
SEAL RING LINE CONNECTION
698
SEAL RING PNEUMATIC VALVE
706
LINE BREATHING
714
HOSE DE-AERATION LINE, ORDER BY THE METER
714
HOSE DE-AERATION LINE, ORDER BY THE METER, Replaced By: A9575011982
722
BREATHER PIPE FROM ENGINE TO EXPANSION TANK
730
HOSE DE-AERATION PIPE TO EXPANSION TANK
738
BANJO UNION HOSE WIDTH, / I.D., 6/10 MM
738
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
746
HOSE CLAMP LINE MOUNTING
746
CLAMP , Replaced By: A0059970190
866
CLAMP LINE MOUNTING
866
CLAMP LINE MOUNTING
866
CLAMP , Replaced By: A3829950101
866
CLAMP SAFETY VALVE AT BRACKET
866
CLAMP STAY TO BRACKET
866
CLAMP LINE MOUNTING
999
SCREW WATER COOLED OIL COOLER
999
BRACKET LINE MOUNTING
999
BRACKET LINE MOUNTING
999
BREATHER PIPE FROM ENGINE TO EXPANSION TANK
999
BRACKET FEED AND RETURN LINES TO ENGINE
999
BRACKET LINE MOUNTING
999
BRACKET LINE MOUNTING
999
COOLING WATER PIPE WATER FEED
999
LINE AT OIL FILTER
