Поз.
Артикул
Описание
113
BOOT FROM AIR CLEANER TO INTAKE PIPE
119
STRAINER BOOT
122
CLAMP BOOT TO AIR DUCT AND TO AIR CLEANER
128
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
128
SCREW , Replaced By: N304017008027
134
WASHER , Replaced By: N000125008443
134
WASHER EXHAUST MUFFLER TO STRAP
137
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
137
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
137
NUT , Replaced By: N913004008001
146
BRACKET , Replaced By: A6575280040
146
BRACKET BOOT
149
SCREW BOOT TO BRACKET
152
BRACKET BOOT
155
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
155
SCREW , Replaced By: N304017008016
158
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
158
NUT , Replaced By: N913004008001
158
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
164
SUPPORT BOOT
170
SCREW BRACKET TO SUPPORT
173
SCREW BRACKET TO SIDE MEMBER
173
SCREW EXHAUST PIPE TO BRACKET
173
SCREW , Replaced By: N304017010002
176
WASHER , Replaced By: N000125010532
176
WASHER , Replaced By: N007349010007
176
WASHER RADIATOR TO RUBBER MOUNTING
176
WASHER STRUT TO CROSS MEMBER
182
NUT STRAP TO BRACKET
182
NUT , Replaced By: N910113010000
