Mercedes A0055429207 - ПРИВОДНОЙ ВАЛ

300 TE 4 MATIC 124.290 TO 09/89

54 ELECTRICAL EQUIPMENT AND INSTRUMENTS - 001 TAXIMETER CONNECTION IL.1

Поз.
Артикул
Описание
12
A0005423247
COUPLER
20
A0055429307
FLEXIBLE SHAFT FROM GEARING TO COUPLER
36
A0055429207
FLEXIBLE SHAFT FROM COUPLER TO SPEEDOMETER
44
A2015421140
BRACKET FLEXIBLE SHAFT TO WHEELHOUSE
52
A0019974190
LOOM TIE , UP TO CHASSIS: 108.012 UNTIL PRODUCTION STOP 108.016 042417 108.018,019 043374 109.016 002452
52
A1149970190
LOOM TIE
52
A0019974390
LOOM TIE TO MOUNT PLASTIC PIPING
52
A1169970890
LOOM TIE
60
A2015421240
BRACKET FLEXIBLE SHAFT TO FRAME SIDE MEMBER, FOR USE WITH AIR CONDITIONER ONLY
70
N914128004303
SHEET METAL SCREW ALARM UNIT TO STRUT
76
N914127004303
SHEET METAL SCREW BRACKET TO WHEEL ARCH PANEL,A 153269
78
N913023006001
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
87
A0004760436
BRACKET LINE MOUNTING 11 MM
92
A1159950365
CLAMP
92
A1109950165
CLAMP HOSE TO HOSE 20 MM
94
A1074280085
DAMPING STRIP BRAKE LINE TO LEFT FRONT WHEELHOUSE PANEL
