Поз.
Артикул
Описание
10
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
20
FITTING (PARTS KIT),LINE RUPTURE
20
FITTING , Replaced By: A0029905971
25
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
27
BANJO UNION , N 000000 P 083147
30
PLASTIC PIPE RISING PIPE 4X6 MM
30
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
40
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
55
UNION NUT
65
GLAND , Replaced By: A0019901667
65
SEAL CONE
75
SLEEVE LEAK LINE
90
HOSE FUEL LINE, ORDER BY THE METER
110
HOSE MASTER SWITCH AND VACUUM SWITCH 40 MM, 023 164780 033 066774 123 158077 130 172061
130
HOSE P.T.O. CONTROL VALVE
140
HOSE (3/2-WAY SOLENOID VALVE) "3"
140
HOSE ENGINE TO REGENERATION VALVE RECHTS, F 125158 EXCEPT CODE 805 ALSO INSTALLED IN VEHICLE TO F 125157 WITH CODE 806
140
HOSE 3/2-WAY VALVE,CONNECTIONS: "1","2"
295
T-FITTING VACUUM LINE TO ENGINE
310
T-FITTING VACUUM LINE
310
T-FITTING BETWEEN THE LINES
310
T-FITTING VACUUM LINE,649390
310
T-FITTING VACUUM LINE TO ENGINE
310
T-FITTING
310
T-FITTING
330
DISTRIBUTOR HOSE WIDTH, 6 MM
340
VALVE BELOW INSTRUMENT PANEL
342
PIN VALVE TO SIDE MEMBER
343
SCREW PIPE CLAMP
344
WASHER EXHAUST MUFFLER TO STRAP
346
NUT STRAP TO BRACKET
390
HOLLOW SCREW HEATING CONNECTION
400
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
