Поз.
Артикул
Описание
14
LINE AIR COMPRESSOR,PRESSURE REGULATOR, DEHYDRATOR 15X1.5 MM, LENGTH AVAILABLE: 3000 MM
22
UNION NUT LINE CONNECTION
30
GLAND LINE CONNECTION
94
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
94
HOSE , Replaced By: A0009872827
102
FITTING (PARTS KIT),LINE RUPTURE
120
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
128
UNION NUT LINE CONNECTION
136
GLAND LINE CONNECTION
144
SLEEVE LINE CONNECTION
152
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
152
BANJO UNION HOSE WIDTH, / I.D., 6/10 MM
152
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
160
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
168
HOLLOW SCREW LINE CONNECTION
176
SEAL RING LINE CONNECTION
184
HOLLOW SCREW HEATING CONNECTION
192
SEAL RING CHECK VALVE,CONNECTION "1",4 704213
200
BREATHER OIL TANK BREATHING, NOT USED
208
WASHER EXHAUST MUFFLER TO STRAP
208
SCREW PIPE CLAMP
208
WASHER , Replaced By: N000125008443
208
SCREW , Replaced By: N304017008021
216
NUT , Replaced By: N913004008001
216
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
224
LOOM TIE LINE MOUNTING 280 MM
224
LOOM TIE LINE MOUNTING
999
CONNECTOR 75 DEGREES
999
CONNECTOR BRAKE POWER REGULATOR,CONNECTION: "30"
999
CONNECTOR BLEEDING
999
CONNECTOR 90 DEG. OFFSET
999
PLASTIC PIPE RISING PIPE 4X6 MM
999
PLASTIC PIPE FUEL LINE 16X2 MM, ORDER BY THE METER
999
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
SCREW. UNION SCREW LINE CONNECTION
999
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
999
VALVE (SOLENOID VALVE)
999
FITTING LINE CONNECTION
999
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
999
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
999
HOSE , Replaced By: A0009872927
999
SEAL RING BLEEDING 19X4 MM
999
FITTING BREATHER LINE TO TRANSFER CASE
999
BRACKET BREATHER LINE
999
SCREW , Replaced By: N000933008134
999
SCREW FRONT AXLE REGULATING SOLENOID VALVE
999
SCREW , Replaced By: N304017008034
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
FITTING FRONT AXLE BREATHING
999
CLAMP CHECK VALVE,K 169122
