Поз.
Артикул
Описание
57
HOSE , Replaced By: A0009872827
57
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
60
FITTING (PARTS KIT),LINE RUPTURE
61
UNION NUT LINE CONNECTION, Replaced By: N000000006239
61
UNION NUT LINE CONNECTION
62
SEAL CONE LINE CONNECTION
62
GLAND , Replaced By: A0019901967
63
SLEEVE LINE CONNECTION
66
DISTRIBUTOR LINE CONNECTION
69
DISTRIBUTOR COMPRESSED AIR LINE
72
SCREW CONSOLE TO REAR CROSS MEMBER M 8X38
75
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
78
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
81
CONNECTOR HOSE WIDTH, 9 MM,TO M 22
84
T-FITTING , Replaced By: A0029909070
84
T-FITTING HOSE WIDTH, 9 MM,TO M 22
87
ELBOW FITTING HOSE WIDTH, 9 MM,TO M 22
999
CONNECTOR REPAIR SIZE
999
T-FITTING
999
CONNECTOR DISTRIBUTOR TO FRAME
999
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
999
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22, 4 MM/9 MM
999
SEAL RING
999
SEAL RING CONNECTOR 11.8X2 MM
999
CLAMP , Replaced By: N916016025200
999
CONNECTOR DISTRIBUTOR TO CAB
999
CONNECTOR , Replaced By: A0019903978
999
CONNECTOR DISTRIBUTOR TO FRAME
999
ELBOW FITTING HOSE WIDTH, 9 MM,TO M 22
999
GROMMET LINE MOUNTING
999
SCREW , Replaced By: N304017006034
999
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
999
SCREW COVER PLATE TO COVER PLATE M 6 X 10
999
CLAMP HOSE TO BRACKET 25/20,5 206397
