Поз.
Артикул
Описание
5
EXHAUST PIPE RESONATOR, TO BE ADAPTED DURING ASSEMBLY
5
EXHAUST PIPE FRONT, TO BE ADAPTED DURING ASSEMBLY
8
SCREW LEFT AND RIGHT CONSOLES TO CAB
8
SCREW , Replaced By: N308676012015
11
NUT , Replaced By: N910113012006
11
NUT THROTTLE HOUSING AND BRACKET TO FRONT EXHAUST PIPE
14
FLEXIBLE METAL TUBE
17
CLAMP FLEXIBLE METAL TUBE TO EXHAUST PIPE
20
SCREW , Replaced By: N304017008067
20
SCREW BRACKET TO RIGHT SIDE MEMBER,5 434014
23
WASHER , Replaced By: N000125008443
23
WASHER EXHAUST MUFFLER TO STRAP
24
NUT , Replaced By: N913004008001
24
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
26
BRACKET , EXHAUST STOCK OF OLD PARTS FROM IDENT NO.5 563226 UP TO IDENT NO.5 599128, Replaced By: A6794910441, +002N000931010282, +002N007349010003
29
CLAMP FLEXIBLE METAL TUBE TO EXHAUST PIPE
32
SCREW , Replaced By: N304017010002
32
SCREW BRACKET TO SIDE MEMBER
35
NUT , Replaced By: N910113010000
35
NUT STRAP TO BRACKET
38
EXHAUST PIPE RESONATOR
41
CLAMP RESONATOR TO FRONT EXHAUST PIPE
44
SCREW BRACKET TO CROSS CONNECTION STRUT
44
SCREW , Replaced By: N304017008034
47
NUT , Replaced By: N913004008001
47
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
50
RESONATOR
53
CLAMP RESONATOR
56
SCREW , Replaced By: N304017010002
56
SCREW BRACKET TO SIDE MEMBER
59
NUT , Replaced By: N910113010000
59
NUT STRAP TO BRACKET
62
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
65
NUT STRAP TO BRACKET
65
NUT , Replaced By: N910113010000
68
BRACKET RESONATOR, NOT USED
68
BRACKET RESONATOR
71
SCREW BRACKET TO SIDE MEMBER
71
SCREW , Replaced By: N304017010002
74
NUT STRAP TO BRACKET
74
NUT , Replaced By: N910113010000
77
PROTECTIVE PLATE FRONT EXHAUST PIPE,5 502998
80
BRACKET , Replaced By: A6764901140
80
BRACKET HEAT SHIELD,5 502998
83
SCREW EXHAUST PIPE TO BRACKET
86
WASHER PROTECTIVE PLATE TO BRACKET,5 502998
89
NUT , Replaced By: N913004008001
89
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
92
PROTECTIVE PLATE CLUTCH SLAVE CYLINDER
95
BRACKET HEAT SHIELD
95
BRACKET HEAT SHIELD
98
SCREW REDUCTION VALVE TO BRACKET
98
SCREW , Replaced By: A0079900801
101
WASHER PROTECTIVE PLATE TO BRACKET,5 502998
104
BRACKET FRONT EXHAUST PIPE TO BRACKET
107
SCREW BRACKET TO SIDE MEMBER
110
FLEXIBLE METAL TUBE FRONT EXHAUST PIPE TO MUFFLER,K 165446
113
CLAMP EXHAUST PIPE TO MUFFLER
113
CLAMP BRACKET TO EXHAUST PIPE
116
SCREW BRACKET TO EXHAUST PIPE,5 528482
119
WASHER , Replaced By: N000125008443
119
WASHER EXHAUST MUFFLER TO STRAP
119
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
122
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
122
NUT , Replaced By: N913004008001
125
EXHAUST MUFFLER
999
SCREW COVERING TO SUPPORT
999
BRACKET AIR INTAKE PIPE,5 551665 TO BE ADAPTED DURING ASSEMBLY
999
RUBBER BUFFER EXHAUST PIPE REAR ON BATTERY CASE
999
BRACKET FUEL LINES TO TRANSMISSION
999
PROTECTIVE PLATE , NOT USED
999
WASHER , Replaced By: N006902011100
999
BRACKET EXHAUST PIPE REAR ON BATTERY CASE
999
BRACKET , Replaced By: A3524920141
999
BRACKET EXHAUST LINE FLEXIBLE METAL TUBE
999
BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO.5 812573 FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO.5 936552, Replaced By: A6754900140
999
BRACKET , EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 227991, Replaced By: A6764902640
999
BRACKET HEAT SHIELD
999
BRACKET BRACKET TO FILTER BRACKET
999
WASHER , Replaced By: N006902011102
999
WASHER UNDERRUN PROTECTION AND BRACKET TO FRAME
999
WASHER HEAT SHIELD TO BRACKET
