Поз.
Артикул
Описание
5
TRANSMISSION CASE FRONT PART, IN THE CASE OF TWIN-H SHIFT,DELIVER ADDITIONALLY:1X 000906 018000
5
TRANSMISSION CASE , FIRST EXHAUST STOCK OF OLD PARTS UP TO TRANSMISSION 001344, Replaced By: A3852603112
9
CYLINDRICAL PIN POWER CYLINDER TO SUPPORT
11
SCREW PLUG TOP AND BOTTOM
15
GASKET CASE PART I TO CASE PART II
15
GASKET , Replaced By: A3852642480
19
CYLINDR. ROLLER BEARING , Replaced By: A0029812425
19
CYLINDR. ROLLER BEARING , Replaced By: A0029814925
19
BALL BEARING
19
BALL BEARING
23
SNAP RING
28
SCREW END PIECE TO EXHAUST PIPE M 10X25
33
LOCK BRAKE SHOE TO BRAKE ANCHOR PLATE, USED WITH HYDRAULIC BRAKE,345.000-008,021,024,025,033 UP TO IDENT NO. FB588185 UP TO CHASSIS FB588185,FROM CHASSIS FB588186,SEE SPARE PARTS LIST 743.0
33
LOCK PLATE BRAKE SHOE TO BRAKE ANCHOR PLATE, UP TO CHASSIS 588185,FROM CHASSIS FB588186,SEE SPARE PARTS LIS T,BM 732.7
39
GEAR (INTERMEDIATE GEAR)
43
LOCK RING DISC SUPPORT
49
SPACER WASHER P.T.O. INTERMEDIATE GEAR
54
SHAFT INTERMEDIATE AXLE
58
SEAL RING FLANGE TO SHAFT
63
CYLINDR. ROLLER BEARING FOLLOWER,571135
63
CYLINDR. ROLLER BEARING , Replaced By: A0069811801
63
CYLINDR. ROLLER BEARING FOLLOWER,571135
69
SCREW CLUTCH TO FLYWHEEL
74
BALL P.T.O. SHAFT
78
GEAR TWIN GEAR
78
GEAR TWIN GEAR
78
GEAR TWIN GEAR
86
LOCK RING P.T.O. INTERMEDIATE GEAR
91
LOCK RING DISC SUPPORT
96
SPACER RING P.T.O. INTERMEDIATE GEAR
102
SPACER TUBE P.T.O. INTERMEDIATE GEAR
106
SHAFT P.T.O. INTERMEDIATE GEAR
111
SEAL RING FLANGE TO SHAFT
116
CYLINDR. ROLLER BEARING , Replaced By: A0069811801
116
CYLINDR. ROLLER BEARING FOLLOWER,571135
116
CYLINDR. ROLLER BEARING FOLLOWER,571135
121
GASKET P.T.O. INTERMEDIATE GEAR
121
GASKET , Replaced By: A3852641980
126
WASHER P.T.O. INTERMEDIATE GEAR
131
SCREW BRACKET TO FRAME SIDE MEMBER
135
BALL P.T.O. SHAFT
141
DRIVE SHAFT
141
DRIVE SHAFT INTERMEDIATE SHAFT
141
DRIVE SHAFT
153
TAPERED ROLLER BEARING
153
TAPERED ROLLER BEARING75 MM
158
TAPERED ROLLER BEARING52 MM
158
TAPERED ROLLER BEARING52 MM
163
SPACER WASHER AS REQUIRED 0.10 MM
163
SPACER WASHER AS REQUIRED 0.30 MM
176
FOLLOWER DRIVE GEAR
181
GEAR DRIVE GEAR
186
NEEDLE BEARING DRIVE GEAR
186
NEEDLE BEARING DRIVE GEAR
191
SPACER WASHER DRIVE GEAR
196
LOCK RING LONGITUDINAL LOCK
201
BALL P.T.O. SHAFT
206
BALL BEARING , Replaced By: A0029812301
206
BALL BEARING , Replaced By: A0089814225
206
BALL BEARING , Replaced By: A0019811525
206
BALL BEARING , Replaced By: A0029812325
206
BALL BEARING DRIVE SHAFT,183596
206
BALL BEARING DRIVE SHAFT,183596
212
GEAR DRIVE
217
NEEDLE BEARING , Replaced By: A0079810010
217
NEEDLE BEARING
224
FITTED WASHER
229
ROLLER ASSEMBLY , Replaced By: A0029813412
229
ROLLER ASSEMBLY
229
ROLLER ASSEMBLY
229
ROLLER ASSEMBLY
229
ROLLER ASSEMBLY
229
ROLLER ASSEMBLY
234
DRIVE SHAFT
239
NEEDLE BEARING DRIVE SHAFT
244
BALL BEARING DRIVE SHAFT,183596
244
BALL BEARING DRIVE SHAFT,183596
244
BALL BEARING , Replaced By: A0089814225
250
SNAP RING DRIVE SHAFT
258
HOUSING REAR
262
SCREW , Replaced By: N304017008008
262
HEXAGON HEAD BOLT PROTECTIVE PLATE TO BRACKET
266
SCREW PLUG HOUSING,BOTTOM,183596
266
SCREW PLUG HOUSING,BOTTOM,183596
271
SEAL RING SHIFTING SHAFT
279
GASKET TRANSMISSION CASE COVER TO TRANSMISSION CASE
279
GASKET , Replaced By: A3852641780
293
SCREW , Replaced By: N304014010004
293
SCREW P.T.O. TO TRANSMISSION M10X100
293
HEXAGON HEAD BOLT CLAMP TO EXHAUST PIPE
293
SCREW MOUNTING AND RAIL TO LEAF SPRING
293
SCREW TRANSMISSION CASE COVER TO TRANSMISSION CASE M 10X75
293
SCREW TRANSMISSION CASE COVER TO TRANSMISSION CASE M 10X140
293
SCREW BRACKET TO FRAME SIDE MEMBER
296
SPRING WASHER STEERING COLUMN BRACKET TO CAB
311
COVER OUTPUT FLANGE,TOP
316
SEAL RING TRANSMISSION CASE REAR COVER,4 473926 FROM IDENT NO. SEE MICROFICHE MODEL 714.0 FROM IDENT NO. SEE MICROFICHE MODEL 714.0
321
GASKET , Replaced By: A3852641880
321
GASKET COVER TO TRANSMISSION CASE
325
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
325
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
325
SPRING WASHER , Replaced By: N000137008212
328
SCREW LINE MOUNTING M 8X45
334
SHAFT (SHIFTING SHAFT), 200-202 FROM TRANSMISSION 002630,203-205 FROM TRANSMISSION 000546
334
SHAFT (SHIFTING SHAFT), 200-202 UP TO TRANSMISSION 002629,203-205 UP TO TRANSMISSION 000545
338
SHIFTING FORK P.T.O. CONTROL
343
SLIDE P.T.O. CONTROL
343
SLIDE , Replaced By: A3852640249
349
CLAMPING PIN SHIFTING FORK TO SHIFTING SHAFT
349
CLAMPING PIN THRUST PIECE TO SHIFTING ROD
353
SLIDING COLLAR P.T.O. CONTROL
359
COVER
363
SEAL RING OUTPUT FLANGE,BOTTOM
368
GASKET , Replaced By: A3852641680
368
GASKET , Replaced By: A6022640280
372
WASHER BRACKET TO LEFT SIDE MEMBER
372
SPRING WASHER CAB FLOOR
372
WASHER MOUNTING USED FOR FRAME CONNECTION PARTS
372
WASHER , Replaced By: N007349013005
376
SCREW BEARING COVER TO TRANSMISSION CASE
381
SHAFT (SHIFTING SHAFT)
386
SHIFTING FORK P.T.O. CONTROL
391
SLIDE , Replaced By: A3852640449
391
SLIDE SHIFTING FORK
396
CLAMPING PIN SHIFTING FORK TO SHIFTING SHAFT
396
CLAMPING PIN THRUST PIECE TO SHIFTING ROD
401
SLIDING COLLAR
406
INTERMEDIATE SHAFT
422
FLANGE TRANSFER CASE
422
FLANGE MAIN SHAFT OUTPUT
427
COUPLING FLANGE OUTPUT FLANGE,TOP, G 3/65-8 SPEED UP TO TRANSMISSION 008151,G 3/65-9 SPEED UP TO TRANSMISSION 001644,G 3/90-8 SPEED UP TO TRANSMISSION 000872
427
COUPLING FLANGE OUTPUT FLANGE,TOP, G 3/65-8 SPEED FROM TRANSMISSION 008152,G 3/65-9 SPEED FROM TRANSMISSION 001645,G 3/90-8 SPEED FROM TRANSMISSION 000873
432
WASHER COUPLING FLANGE TO DRIVE SHAFT
436
SCREW FOLLOWER FLANGE TO PROPELLER SHAFT
438
GEAR DRIVE
440
LOCK RING. RETAINING RING OIL PUMP TO TRANSMISSION CASE
443
COUPLING FLANGE
446
WASHER FLANGE TO SHAFT
451
SCREW FLANGE TO SHAFT
451
SCREW , ONLY INSTALL 360 990 13 04,SEE SERVICE INFORMATION DATED 15.07.1977,GROUP 03/33, Replaced By: A3609901304
999
PIN
999
COVER
999
TRANSMISSION CASE COVER
999
TRANSMISSION CASE COVER
999
GASKET , Replaced By: A3852642580
999
PIN SHIFT LEVER TO PIVOT PIN
