Поз.
Артикул
Описание
1
WHEELHOUSE LEFT, FROM CHASSIS:111.021 084687 112.021 009183 111.024 000001
2
WHEELHOUSE INSIDE LEFT
3
ROOF RAIL
4
ROOF PANELLING , FROM CHASSIS 031345 WHEN NO ELECTRIC DRIVE HAS BEEN INSTALLED,INSERT 110 782 00 39 FILLER
5
FRAME BOTTOM
6
RUBBER BUFFER , 023 033484 033 018824 123 022270 130 030352
8
SEAL , FROM CHASSIS:110.010 155808 110.110 274548 111.010 088651, Replaced By: A0039895485
10
GROMMET
11
HOSEWASSERABLAUF HINTEN 250 MM
12
CLIP FLEXIBLE SHAFT TO WHEELHOUSE, 086 007397 093 010089 183 NOT FOR SWEDEN 028930 183 SWEDEN F 001867 ALSO INSTALLED ON 028960 190 030466 ALSO INSTALLED ON 030442 193 005964 280 NOT FOR SWITZERLAND 009681 ALSO INSTALLED ON 009608,009626-009679 280 SWITZERLAND 009208 283 NOT FOR SWITZERLAND 019905 ALSO INSTALLED ON 019489,019510,019514,019524,019528-019534,019541,019543,019548-019550,019554-019575,019587,019590, 019593,019603,019604,019613,019614,019625-019638,019646,019649-019712,019715-019814,019821,019830- 019894,019899,019901. 283 SWITZERLAND F 000423 ALSO INSTALLED ON 021312,F 000333
13
PAD FRAME PART,CENTRAL 860 MM
36
GROMMET LINE PASSAGE AT SIDE MEMBER 24 MM,5 473494
86
PANELLING , STATE COLOR NUMBER WHEN ORDERING
87
BOW
88
BOW FIRST,FROM THE REAR, FROM CHASSIS: 111.021 021522
999
PLUG , Replaced By: A0025454928
999
FUSE BOX , Replaced By: A0005459901
999
PLUG , Replaced By: A0025452428
999
FUSE , Replaced By: N072581008101
999
FUSEA16
999
FUSE FUSE BOX A 25
999
FUSE BOX BIPOLAR,K 100807 MIT AUSNANME VON K 093739
999
ELECTRIC MOTOR , Replaced By: A0008201142
999
ELECTRIC MOTOR , Replaced By: A0008201142
999
ELECTRIC MOTOR
999
GEARING , Replaced By: A0008203207
999
CONNECTOR 4-POLE
999
SWITCH , UP TO CHASSIS: 111.021 069792 112.021 007132, Replaced By: A0018210651, +001A0008210126
999
FOAM PLASTICS , Replaced By: A0009833598
999
FOAM PLASTICS , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0009831298
999
FOAM PLASTICS , Replaced By: A0009831298
999
FOAM PLASTICS ROOF INTERIOR COVERING,7X80X100, ORDER BY THE METER
999
FOAM PLASTICS 10 MM, ORDER BY THE METER
999
CARPET *** 2 MM, ORDER BY THE METER
999
FELT60X20X2 MM, ORDER BY THE METER
999
FOAM PLASTICS FRONT ROOF RAIL
999
HOSE
999
RUBBER PAD , Replaced By: A1107841597
999
RUBBER SEAL , FROM CHASSIS:110.010 155808 110.011 013995 110.110 274548 111.010 088651 THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0039895485
999
CLIP CABLE HARNESS TO ROOF RAIL
999
CLIP
999
NUT RETAINER HEATER CASE TO FIRE WALL
999
NUT RETAINER , FROM CHASSIS:111.021 088365 111.024 000001 112.021 009718
999
BUSHING MOTOR TO BRACKET
999
FUSE25 A
999
CLIP , Replaced By: A0019881778
999
CLIP , Replaced By: A0009881778
999
GROMMET GEARING TO BRACKET
999
LOOM TIE , Replaced By: A0019974390
999
LOOM TIE TO MOUNT PLASTIC PIPING
999
PLUG , Replaced By: A0085453728, +002A0035452626, +001A0085453828
999
CLIP , Replaced By: A1089880978
999
ADHESIVE TAPE (SEAL),BETWEEN OUTSIDE REAR PILLAR AND ROOF 560 MM, ORDER BY THE METER
999
PIN BUSHING HOUSING , 10/20 UP TO CHASSIS 4 411810,50/60 UP TO CHASSIS 4 414810
999
SCREW
999
INSULATION BETWEEN REINFORCEMENT AND ROOF PANELLING 40X520X10 MM, ORDER BY THE METER
999
FRAME , STATE COLOR NUMBER WHEN ORDERING
999
PLATE
999
TUBE , Replaced By: A1087800217
999
LOCK LEFT
999
PLATE RIGHT
999
SEAL , Replaced By: A1157820098
999
RAIL RIGHT
999
SLIDING RAIL FRONT RIGHT
999
SLIDING RAIL RIGHT
999
SEAL , Replaced By: A1107870098
999
RUBBER BUFFER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1159870240
999
CLAMP FUEL LINE TO BRACKET
999
WHEELHOUSE INSIDE RIGHT
999
WHEELHOUSE , Replaced By: A1116306369
999
WHEELHOUSE , Replaced By: A1116306469
999
WHEELHOUSE
999
ROOF RAIL , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS 111.021 088724 112.021 009795, Replaced By: A1116505501
999
BRIDGE , Replaced By: A1117805135
999
BRACKET LESS MOTOR AND GEARING
999
SLIDING ROOF PLATE , UP TO CHASSIS: 110.010 181595 110.110 337418 110.011 028385 111.010 103769, Replaced By: A1117805521, +002A1089900222, +002A0009909091, +002N009021005203
999
TUBE , Replaced By: A1117805377
999
BRACKET WITH MOTOR AND GEARING, FROM CHASSIS:111.024 005154 111.026 003786 NO LONGER AVAILABLE,ORDER INDIVIDUAL PARTS
999
LOOM TIE , Replaced By: A1149970590
999
LOOM TIE , Replaced By: A1149970290
999
LOOM TIE
999
SLIDING JAW , 023 143560 033 058449 123 130866 130 149678
999
SLIDING JAW , NOT USED
999
SEAL
999
CLAMP , Replaced By: A3449957120
999
GROMMET 34 MM
999
CLAMP TO MOUNT MAIN CABLE HARNESS
999
CLAMP , Replaced By: A1109950401
999
SCREW FUSE BOX TO SIDE MEMBER,5 097182
999
SCREW
999
WASHER , Replaced By: N000125004319
999
WASHER BRACKET TO SUPPORT
999
WASHER , UP TO CHASSIS: 017 029988 114 000523 117 064694
999
WASHER
999
LOCK WASHER BRACKET TO COVERING
999
LOCK WASHER. SPRING LOCK WASHER ELECTRIC CABLE TO HORN TO 004 542 44 20 /45 20
999
SCREW COVER PLATE TO BRACKET
999
SCREW , Replaced By: N304017006034
999
SCREW CAB FLOOR COVERING M 6X25
999
SCREW COVER PLATE TO BRACKET
999
SCREW
999
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
NUT BALL PIVOT TO LEVER
999
SCREW GUIDE TO STEERING COLUMN END,4 430730
999
SCREW
999
TOOTHED WASHER COVER TO COVERING,K 093739
999
TOOTHED WASHER MASKED STOP LAMP
999
SHEET METAL SCREW
999
SHEET METAL SCREW , Replaced By: N007981002322
999
SHEET METAL SCREW TACHOGRAPH
999
SHEET METAL SCREW
999
SHEET METAL SCREW , Replaced By: N000000002062
999
SHEET METAL SCREW
999
SCREW ELECTRIC CABLE TO HORN
999
SCREW
999
SCREW , Replaced By: N000000001933
999
SCREW
999
WASHER , Replaced By: N009021004207
999
WASHER COVERING TO CYCLONE AIR TRAP
999
WASHER , Replaced By: N009021005205
999
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
999
WASHER , Replaced By: N009021006208
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
FUSEA8
999
SCREW COVER PLATE TO COVER PLATE M 6 X 10
999
CLAMP CABLE HARNESS MOUNTING 22 MM
999
LOCK WASHER T-FITTING TO BRACKET
999
LOCK WASHER BRACKET TO STEERING COLUMN END
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
