Поз.
Артикул
Описание
5
COVERING LEFT
10
NUT RETAINER , Replaced By: A3229900091
12
COVERING
15
COVERING
17
COVERING LEFT, STATE COLOR NUMBER WHEN ORDERING
20
COVERING LEFT, STATE COLOR NUMBER WHEN ORDERING
23
SCREW
23
SCREW , Replaced By: A0009905836
76
HEADLINER , STATE COLOR NUMBER WHEN ORDERING
92
DRIP MOULDING LEFT
94
DRIP MOULDING LEFT, 100001
100
PAD
102
PAD , 100001
105
COVERING , 100001
134
ORNAMENTAL COVER LEFT
136
ORNAMENTAL COVER LEFT, 100001
141
PAD , 003041
143
SPACER
148
TREENAIL
162
GARNISH MOULDING RIGHT
164
WELT
167
RIVET , 000022
169
SEAL RING
171
ORNAMENTAL COVER OUTSIDE LEFT, 100001
174
ORNAMENTAL COVER INSIDE LEFT, 100001
177
ORNAMENTAL COVER LEFT, 100001
182
SEAL LEFT
187
ADAPTER LEFT, 100001
190
PAD , 100001
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
SCREW COVER PLATE TO COVER PLATE M 6 X 12
999
WASHER COVERING TO CYCLONE AIR TRAP
999
WASHER , Replaced By: N009021004207
999
SHEET METAL SCREW
999
SHEET METAL SCREW
999
SHEET METAL SCREW
999
SHEET METAL SCREW COVERING TO HOUSING
999
SHEET METAL SCREW OIL LINE MOUNTING
999
SHEET METAL SCREW , Replaced By: N000000002062
999
SHEET METAL SCREW. TAPPING SCREW , Replaced By: N007981003203
999
SHEET METAL SCREW
999
SHEET METAL SCREW BRACKET TO CAB FLOOR
999
SHEET METAL SCREW BRACKET TO CAB
999
SHEET METAL SCREW TACHOGRAPH
999
SHEET METAL SCREW COVER TO CASE
999
SHEET METAL SCREW , Replaced By: N007981002306
999
SHEET METAL SCREW , NOT USED
999
SHEET METAL SCREW BRACKET TO CAB FLOOR
999
SHEET METAL SCREW
999
TOOTHED WASHER
999
SCREW , Replaced By: N304017006018
999
WASHER , UP TO CHASSIS: 017 029988 114 000523 117 064694
999
SCREW
999
SCREW
999
SCREW , Replaced By: A0009908636
999
GARNISH MOULDING LEFT
999
ORNAMENTAL COVER , Replaced By: A1156901689
999
DRIP MOULDING , FROM CHASSIS: 073 100001
999
ORNAMENTAL COVER , Replaced By: A1156901589
999
DRIP MOULDING , UP TO CHASSIS: 073 100000
999
ORNAMENTAL COVER OUTSIDE RIGHT, FROM CHASSIS: 073 100001
999
ORNAMENTAL COVER RIGHT
999
SEAL RIGHT, FROM CHASSIS: 015 200001 110 400001 115 200001 005,017,105,107,108,117,119 000001
999
GARNISH MOULDING RIGHT
999
ADAPTER RIGHT, 100001
999
PAD RIGHT
999
COVERING
999
COVERING RIGHT
999
ORNAMENTAL COVER RIGHT, FROM CHASSIS: 015 200001 110 400001 115 200001 005,017,105,107,108,117,119 000001
999
ORNAMENTAL COVER RIGHT, FROM CHASSIS: 073 100001
999
COVERING BOTTOM INSIDE RIGHT
999
ORNAMENTAL COVER INSIDE RIGHT, 100001
999
COVERING RIGHT
999
EDGING RIGHT
999
GARNISH MOULDING RIGHT
999
COVERING RIGHT, STATE COLOR NUMBER WHEN ORDERING
999
COVERING RIGHT, STATE COLOR NUMBER WHEN ORDERING
999
PANELLING LEFT
999
GARNISH MOULDING RIGHT
999
PANELLING RIGHT, STATE COLOR NUMBER WHEN ORDERING FROM CHASSIS: 023 008703, ALSO INSTALLED ON: 008681-008685,008687,008688,008691-008701. UP TO CHASSIS: 073 103728, FEDERAL, EXCEPT FOR: 103388,103528,103535,103585,103608,103707,103715,103717,103722. 073 103835, CALIFORNIA, EXCEPT FOR: 103522,103523,103542,103557,103582,103727,103741,103742,103758-103760,103778,103786,103791,103799, 103800,103803,103809-103815,103819,103820,103822,103824,103830-103834.
999
PANELLING LEFT, STATE COLOR NUMBER WHEN ORDERING FROM CHASSIS: 023 008703, ALSO INSTALLED ON: 008681-008685,008687,008688,008691-008701. UP TO CHASSIS: 073 103728, FEDERAL, EXCEPT FOR: 103388,103528,103535,103585,103608,103707,103715,103717,103722. 073 103835, CALIFORNIA, EXCEPT FOR: 103522,103523,103542,103557,103582,103727,103741,103742,103758-103760,103778,103786,103791,103799, 103800,103803,103809-103815,103819,103820,103822,103824,103830-103834.
999
SCREW PANELLING TO FRONT SEAT BACKREST
999
NUT RETAINER , Replaced By: A0009907191
999
FASTENER BUTTON , Replaced By: A0009881581
999
STRIP LEFT REAR ROOF RAIL, ORDER BY THE METER
999
STRIP
999
CARDBOARD3 MM, ORDER BY THE METER
999
FABRIC 150 X 500 MM, WHEN ORDERING,STATE COLOR,CHASSIS NO.,AND DIMENSIONS
