Поз.
Артикул
Описание
107
IGNITION DISTRIBUTOR
108
DISTRIBUTOR CAP
113
OILER IN HOUSING. GREASE CUP
115
RUBBER RING
118
CONTACT SET. POINT UNIT
121
DISTRIBUTOR
130
CONDENSER , 92310/50,20/60 007894 92312/52,22/62 034662 93310/50,20/60 000854 93312/52,22/62 000128
139
FOLLOWER
141
WASHER
142
SCHEIBE. SPACER WASHER AS REQUIRED 0.1 MM
145
PIN
146
PIN
148
SNAP RING. LOCK WASHER
149
IGNITION CABLE
151
RUBBER RING
153
REPAIR KIT
155
GASKET KIT
157
BEARING HOUSING
158
TIMING LEVER , UP TO ENGINE 920 10/50,20/60 030437 920 12/52,22/62 007048 921 001457 923 10/50,20/60 030550 923 12/52,22/62 004783 UP TO ENGINE 924 10/50,20/60 000715 924 12/52,22/62 000030 926 10/50,20/60 001281 926 12/52,22/62 000039 928 000377
160
SCREW SHIM TO LEAF SPRING
160
SCREW , Replaced By: N000912006175
160
SCREW , Replaced By: A0019907212
162
SCREW , Replaced By: N304017006016
162
SCREW PUMP TO BRACKET
163
SPRING WASHER LICENSE PLATE TO BRACKET
167
HEXALOBULAR BOLT. SCREWM 8X45
167
SCREW , Replaced By: N000000001448
168
WASHER BRACKET TO CROSS MEMBER
169
INTERMEDIATE RING. SPACER RING
192
IGNITION CABLE
193
IGNITION CABLE
195
IGNITION CABLE
197
INTERMEDIATE PIECE , TO 180 150 21 18,180 150 22 18, 180 150 23 18
198
SEAL RING
200
PIN
201
BRACKET , UP TO ENGINE 923 10/50,20/60 142462 923 12/52,22/62 026809 926 10/50,20/60 007796 926 12/52,22/62 000297
203
BRACKET , UP TO ENGINE 923 10/50,20/60 142462 923 12/52,22/62 026809 926 10/50,20/60 007796 926 12/52,22/62 000297
205
SCREW , Replaced By: N304017008039
205
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
207
SPRING WASHER , Replaced By: N000137008212
217
IGNITION CABLE
221
SPARK PLUG14-6 DUO BERU
221
SPARK PLUGW 6 DCO BOSCH
221
SPARK PLUG
999
INTERMEDIATE PIECETO 130 150 31 18/32 18/33 18
999
SHIM 0.1 MM THICK. SPACER WASHER AS REQUIRED 0.2 MM
999
PIN , TO 130 150 31 18,130 150 32 18, 130 150 33 18
999
SPARK PLUG
999
SCREW ELECTRIC CABLE THRU ENGINE CROSS MEMBER
999
LOCK WASHER. SPRING LOCK WASHER ELECTRIC CABLE TO HORN TO 004 542 44 20 /45 20
999
WASHER BRACKET TO HEAT SHIELD
999
SCREW , Replaced By: N000912006175
999
SCREW , Replaced By: A0019907212
999
LOCK WASHER T-FITTING TO BRACKET
