Поз.
Артикул
Описание
140
SUPPORT
141
NEEDLE BEARING
142
SCREW
143
SPRING WASHER , Replaced By: N000137008212
144
NUT
145
SCREW
146
SPRING WASHER LICENSE PLATE TO BRACKET
151
LEVER
152
NEEDLE BEARING
153
LEVER
154
GUIDE PIVOT
155
SCREW COVER PLATE TO BRACKET
156
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
157
SLOTTED GATE
158
SCREW COVER PLATE TO BRACKET
158
SCREW PUMP TO BRACKET
159
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
160
WASHER , UP TO CHASSIS: 017 029988 114 000523 117 064694
163
SPRING WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
164
WASHER
165
LOCK PLATE INTERMEDIATE BEARING
166
SPRING WASHER , Replaced By: N000137008212
167
NUT
168
SHIFTING TUBE
175
SHIFT LEVER , 019136
177
PIN
179
CAP
180
SPRING SHIFTING TUBE
181
CLAMPING SLEEVE , Replaced By: N001481005017
181
CLAMPING SLEEVE
184
SPRING
185
GUIDE PIVOT
186
SEAL RING , FROM CHASSIS: 007,008,015,017 235920 011 106975 060 114910 062 106278
187
WASHER
188
LOCK
189
BOOT
215
WASHER
216
WASHER
225
BALL SOCKET
225
BALL SOCKET , Replaced By: A0002681266
231
GROMMET , Replaced By: A1269972581
231
GROMMET
241
LOCK
242
KNOB , FROM CHASSIS: 005,007,008,015,017: 10/50 090635 010: 10/50 068828 LESS POWER STEERING 005,007,008,015,017: 12/52 092483 010: 12/52 069820 LESS POWER STEERING 005,007,008,015,017: 20/60 095154 010: 20/60 070957 LESS POWER STEERING 005,007,008,015,017: 22/62 093766 010: 22/62 070344 LESS POWER STEERING 005,007,008,015,017: 10/50 092329 010: 10/50 069673 WITH POWER STEERING 005,007,008,015,017: 12/52 089128 010: 12/52 068019 WITH POWER STEERING 005,007,008,015,017: 20/60 095064 010: 20/60 070899 WITH POWER STEERING 005,007,008,015,017: 22/62 092472 010: 22/62 069811 WITH POWER STEERING
251
BRACKET
252
SCREW
253
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
254
NUT BALL PIVOT TO LEVER
999
SCREW
999
SEAL RING , UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359
999
LOOM TIE , UP TO CHASSIS: 108.012 UNTIL PRODUCTION STOP 108.016 042417 108.018,019 043374 109.016 002452
999
BALL SOCKET
999
LAMP SOCKET
999
SEAL RING
999
SHIFTING ROD , FROM CHASSIS: 015 200001 011,060 100001
999
SUPPORT FRONT
999
SHIFTING TUBE , FROM CHASSIS: 000,002,010 053750 015 057120 100,102,103,110,112 132391 115 061803 005,017,105,107,108,117,119 000001
999
YOKE , Replaced By: A1152601353, +001A1269930120
999
BEARING , Replaced By: A1152673505, +001A1262670123, +001A1269930120
999
BUSHING , UP TO CHASSIS: 000,002,010 056141 015 060261 100,102,103,110,112 139360 115 065085 FROM CHASSIS: 000,002,010 095002 015 115531 100,102,103,110,112 244263 115 122228
999
KNOB
999
CABLE HARNESS
999
BUSHING , 114.005,007,015 037181 114.010 033492 114.021 001931 114.022 002382 115.000,002,010 037475 115.015 035971 115.100,102,110 085311 115.115 039087
999
BUSHING GEAR SELECTOR LEVER
999
NUT TACHOGRAPH TO BRACKET
999
NUT
