Поз.
Артикул
Описание
1
ACCELERATOR PEDAL
2
JOINT ,B 859430
3
ACCELERATOR PEDAL
3
PAD , Replaced By: A1233000204
5
LEVER
6
BRACKET , Replaced By: A1249888678
6
CLIP
7
BEARING
10
CLIP PRE-GLOW TIME RELAY TO COWL
11
WASHER COMPRESSED AIR LINE TO BRACKET
11
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
12
SHEET METAL SCREW
13
GROMMET
18
SPRING
19
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
19
SCREW , Replaced By: N304017008016
20
SPRING WASHER , Replaced By: N000137008212
21
WASHER , Replaced By: N000125008443
26
STOP
27
SEAL RING KICK-DOWN SWITCH
46
BALL SOCKET , Replaced By: A0009918922
46
BALL SOCKETTO 102 070 09 75, Replaced By: A0009930461
47
NUT TACHOGRAPH TO BRACKET
50
WIRE CABLE
51
NUT
52
BUTTON IDLING ADJUSTMENT,303364
55
END PIECE WIRE CABLE
56
SCREW
76
RUBBER BUFFER
999
KICK-DOWN SWITCH , FROM CHASSIS: 011: 12/52 100001 007,008,015,017: 12/52 200001
999
BUTTON. KNOB
999
SHAFT
999
ROD
999
PAD , Replaced By: A1233000204
999
BOOT
