Поз.
Артикул
Описание
10
HEATING UNIT , A 21821620010731 F 20660820011031
10
HEATER UNIT , Replaced By: A2035004998
10
HEATER , A 55589720030630804 F 45737520031014804, Replaced By: A2035004798
15
BURNER INSET HEATING
20
BRACKET HEATER UNIT
25
SCREW HEATER UNIT TO BRACKET, F 155735 EXCEPT CODE 807 ALSO INSTALLED IN VEHICLE TO F 155734 WITH CODE 808
30
EXHAUST PIPE AT HEATER
40
MUFFLER EXHAUST MUFFLER
50
END PIECE INDEPENDENT HEATING
60
CLAMP EXHAUST PIPE
65
TAPPING SCREW
70
FRONT EXHAUST PIPE , F 155735 EXCEPT CODE 807 ALSO INSTALLED IN VEHICLE TO F 155734 WITH CODE 808
80
HOSE AT HEATER
85
CLAMP
90
LOOM TIE , F 155735 EXCEPT CODE 807 ALSO INSTALLED IN VEHICLE TO F 155734 WITH CODE 808
100
FAN SHROUD AIR INTAKE
140
HEXALOBULAR BOLT BRACKET TO BRACKET M8X16
170
STICKER INDEPENDENT HEATING, E 01938620050630805 A 66602420040430805 F 59396620040531805 NO LONGER AVAILABLE
170
STICKER INDEPENDENT HEATING, E 01872520030630804 A 55589720030630804 F 45737520031014804
175
CIRCULATION PUMP
175
CIRCULATION PUMP
180
PIPE HOSE TO CHECK VALVE
185
CLAMP. LOOM TIE
190
HOSE LINE TO COMPENSATING TANK, WATER PUMP AND HEATER UNIT
192
HOSE HEATER ON PIPE
197
CLAMP HOSE FASTENING 28-35 MM,V 207570
200
HOSE CHECK VALVE TO HEATER UNIT
210
HOSE CLAMP HOSE ATTACHMENT 27 MM
220
DAMPING STRIP LINE CLIP FUEL LINE FOR STATIONARY HEATER
240
CLAMP AT SIDE MEMBER
250
CLAMP LINE AUX.HEATER LEFT REAR SEAT FLOOR
260
NUT COVERING TO CAB FIRE WALL
270
LINE HOLDER
395
HOSE
395
HOSE
400
HOSE COMBINATION VALVE (FEED TO VEHICLE HEATING)
405
HOSE CLAMP HOSE ATTACHMENT 27 MM
410
HOSE COMBINATION VALVE TO COUPLER
415
VALVE
420
CLAMP25 MM
425
HOSE CHECK VALVE TO COMBINATION VALVE
430
VALVE CHECK VALVE
435
CLAMP. LOOM TIE
440
HOSE FROM CHECK VALVE TO PIPE LINE
610
HOSE FROM RECIRCULATING PUMP TO ENGINE, E 00517820010731 A 23717320010831 R 04833720020204
670
CLAMP. LOOM TIE
