Поз.
Артикул
Описание
10
PILLAR A-PILLAR,RIGHT
10
PILLAR A-PILLAR,LEFT
20
BRACKET RIGHT REINFORCEMENT
20
BRACKET LEFT REINFORCEMENT
30
A-PILLAR A-PILLAR,LEFT
30
A-PILLAR A-PILLAR,RIGHT
40
ROOF RAIL ROOF RAIL,LEFT
40
ROOF RAIL ROOF RAIL,RIGHT
50
SIDE PANEL C-PILLAR LEFT INSIDE
50
SIDE PANEL C-PILLAR RIGHT INSIDE
60
REINFORCEMENT RIGHT DOOR EDGE
60
REINFORCEMENT LEFT DOOR EDGE
70
WHEELHOUSE REAR RIGHT
70
WHEELHOUSE REAR LEFT
80
END PIECE REAR RIGHT
80
END PIECE REAR LEFT
90
PILLAR B-PILLAR,INSIDE LEFT
90
PILLAR B-PILLAR,INSIDE RIGHT
100
SUPPORT LEFT
100
SUPPORT RIGHT
110
STRUT LEFT
110
STRUT RIGHT
130
SIDE PANEL SIDE PANEL,LEFT
130
SIDE PANEL SIDE PANEL,RIGHT
135
PANELLING LEFT
135
PANELLING RIGHT
140
PILLAR LEFT
140
PILLAR RIGHT
150
ROOF RAIL LEFT
150
ROOF RAIL RIGHT
160
REINFORCEMENT RIGHT
160
REINFORCEMENT LEFT
170
ROOF RAIL ROOF RAIL,RIGHT
170
ROOF RAIL ROOF RAIL,LEFT
180
PILLAR C-PILLAR OUTSIDE LEFT
180
PILLAR C-PILLAR OUTSIDE RIGHT
190
REINFORCEMENT TOP RIGHT
190
REINFORCEMENT TOP LEFT
200
SEAL TOP RIGHT
200
SEAL TOP LEFT
210
HEXALOBULAR BOLT BRACKET ON TUBULAR SUPPORTING FRAMEWORK M6X12
220
NUT-AND-WASHER ASSEMBLY RUBBER MOUNTING TO FRAME M8
230
SUPPORT RIGHT
230
SUPPORT LEFT
240
END PIECE RIGHT
240
END PIECE LEFT
250
SUPPORT LEFT FRONT SIDE MEMBER
250
SUPPORT RIGHT FRONT SIDE MEMBER
260
RIVETED NUT A-PILLAR, LEFT AND RIGHT
300
LINE HOLDER WATER DRAIN
500
SCREW (PARTS KIT) PARTITION PANEL TO WHEELHOUSE
510
BLIND RIVET REPAIR SOLUTION 6,4 X 12MM / 1-3,5MM, NO LONGER AVAILABLE RIVET ONLY VALID FOR BR222. REPAIR INFORMATION SEE WIS. ADDITIONAL INFORMATION ON TECHNICAL MARKET SUPPORT
