Mercedes A0165451428 - ШТИФТ ШТЕКЕРА

E 280 210.063 TO MODELLJAHR CODE 809

54 ELECTRICAL EQUIPMENT AND INSTRUMENTS - 121 ENGINE CABLE HARNESS,BODY MOUNTED IL. 2

Поз.
Артикул
Описание
269
A2105407432
ELECTRIC CABLE AUXILIARY HEATER, TO BE ADAPTED DURING ASSEMBLY
272
A1405450026
PLUG SOCKET DIAGNOSIS BOX
275
A0035454826
ROUND PIN BUSHING1 MM
278
A0008210565
CASE 4-POLE
281
A0025459926
ROUND PIN BUSHING2.5 MM2
284
A1405453528
PLUG INJECTION VALVE
287
A0055456826
CONTACT SPRINGTO 657 540 50 10
290
A0085458226
CONTACT SPRING UNIPOLAR 0.35-1.0 MM2
290
A0065453626
CONTACT SPRING0.35-1.0 MM2, 1POLIG, A 218853 ALSO INSTALLED ON A 103237 - A 218851 WITH CODE 030 F 190066 ALSO INSTALLED ON F 159752 - F 190064 WITH CODE 030 EXCEPT FOR A 219847
290
A0085458326
FEMALE CONTACT. CONTACT SPRING , Replaced By: A0085458226
293
A0165451428
PLUG PIN0.5-2.0 MM2
999
A0002035464
VALVE
999
HWA2105069940
BRACKET INDEPENDENT HEATING
999
N000934006013
NUT CYLINDER TO BRACKET TO0002902112
999
N914130006200
SCREW , Replaced By: N910106006000, +001N000125006421
