Поз.
Артикул
Описание
10
TRUNK LID , A 37260220020901803
10
TRUNK LID , A 26505420020930802
15
SEAL REAR LID
15
SEAL REAR LID, Replaced By: A2206390797
20
HINGE LEFT, A 32444920021106 P A 326361 A 32444920021106MA 317415, Replaced By: A2207500787
20
HINGE RIGHT, A 32444920021106 P A 326361 A 32444920021106MA 317415, Replaced By: A2207500887
20
HINGE LEFT, A 32444920021106 P A 326361 A 32444920021106MA 317415, Replaced By: A2207500987, +001A2207501087, +002A2207580044, +002A2209801064
20
HINGE RIGHT, A 32444920021106 P A 326361 A 32444920021106MA 317415, Replaced By: A2207501087, +001A2207500987, +002A2207580044, +002A2209801064
20
HINGE RIGHT, A 32445020021106 P A 317415 A 32445020021106MA 326361
20
HINGE LEFT, A 32445020021106 P A 317415 A 32445020021106MA 326361
20
HINGE LEFT
20
HINGE RIGHT
22
CAP HINGE
25
DRIVE RIGHT
30
BOLT LOCKING CLAMP TO REAR END CENTRAL PART M6X14
32
BOLT HINGE TO REAR PANEL M6X16
35
BOLT HINGE TO REAR PANEL M6X16
37
NUT , Replaced By: N913023006001
40
BOLT LOCKING CLAMP TO REAR END CENTRAL PART M6X14
55
STOP ON REAR LID HINGE
55
STOP AT TRUNK LID, BOTTOM
60
BUFFER ON REAR LID HINGE, NOT USED
70
BUFFER LEFT, FROM CHASSIS: 010 077937
80
INTERMEDIATE LAYER REAR LID STOP 22 MM, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. J 23247820061012, Replaced By: A1698891295
100
POTENTIOMETER REMOTE TRUNK RELEASE
110
SWITCH REMOTE TRUNK LOCKING WITH KEYLESS GO
110
SWITCH REMOTE TRUNK LOCKING
120
RUBBER BUFFER REAR LID STIFFENING
130
SPRING HINGE, A 32444920021106 P A 326361 A 32444920021106MA 317415
135
SPRING RIGHT, A 00618920000331
135
SPRING LEFT, A 09777519991130
135
SPRING LEFT, A 00618920000331
135
SPRING RIGHT, A 09777519991130
137
GAS-OPERATED SPRING HINGE, A 32445020021106 P A 317415 A 32445020021106MA 326361
138
STOP TO TRUNK LID LIMIT STOP HINGE, A 03808420030514
140
SEAL ON REAR LID
150
PANELING REAR LID
150
PANELING REAR LID
150
PANELING REAR LID
150
PANELING REAR LID
160
EXPANSION RIVET REAR LID
170
COVER REAR LID PANELLING
180
HANDLE FASTENER
180
HANDLE FASTENER
180
HANDLE FASTENER
180
HANDLE FASTENER
180
HANDLE FASTENER
180
HANDLE FASTENER
180
HANDLE FASTENER, Replaced By: A2207500193
190
TAPPING SCREW CONTROL UNIT TO FIRE WALL
200
LOCK FUEL LINE
200
LOCK NUT MOUNTING, COVER, THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0019900856
220
PLUG
