Поз.
Артикул
Описание
5
INJECTION PUMP
10
SEAL RING , Replaced By: A0149976148
15
BALL PIVOT GOVERNOR SHAFT LEVER
20
DRIVE GEAR INJECTION PUMP
25
WOODRUFF KEY
30
NUT TRAILER COUPLING TO FRAME
35
LOCK WASHER RAIL TO SUBSTRUCTURE
40
SUPPORT FOUR-HOLE MOUNTING
45
WASHER BEARING BRACKET TO SIDE MEMBER
50
NUT , Replaced By: N304032010002
55
STUD SUPPORT TO INJECTION PUMP M10X35,129616
60
SCREW BRACKET TO INTAKE MANIFOLD
65
SEAL RING COVER TO TIMING CASE
70
HOLLOW SCREW
75
SEAL RING INJECTION PUMP
80
PRESSURE VALVE PRESSURE RELIEF
85
SEAL RING INJECTION PUMP
90
HOSE , Replaced By: A0089979082
95
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
100
FITTING RETURN LINE
105
UNION NUT RETURN
110
BANJO BOLT. HOLLOW SCREW
115
SEAL RING LINE CONNECTION
120
SCREW FITTING
125
SEAL RING LINE CONNECTION
130
LOOM TIE LINE MOUNTING 150 X 3,6 MM
