Поз.
Артикул
Описание
474
TAIL LAMP , Replaced By: A0015444003
474
TAIL LAMP LEFT HELLA,4 300928
474
TAIL LAMP , Replaced By: A0015444503
474
TAIL LAMP LEFT R & S,4 300928
474
TAIL LAMP , Replaced By: A0015444203
474
TAIL LAMP RIGHT HELLA,4 300928
474
TAIL LAMP , Replaced By: A0015444803
474
TAIL LAMP RIGHT R & S,4 300928
474
TAIL LAMP , Replaced By: A0015444103
474
TAIL LAMP RIGHT HELLA,4 300928
474
TAIL LAMP , Replaced By: A0015444603
474
TAIL LAMP RIGHT R & S,4 300928
474
TAIL LAMP , Replaced By: A0015444303
474
TAIL LAMP , Replaced By: A0015445903, +001A0009871344
474
TAIL LAMP LEFT HELLA,4 300928
474
TAIL LAMP LEFT R & S,4 300928
476
TAIL LAMP , Replaced By: A0005447403
476
SPARE PART BOX , Replaced By: A0015446103
476
LENSHELLA,4 300928
476
LENS , Replaced By: A0015445990
476
LENSR & S,4 300928
478
GASKET , Replaced By: A0005448480
478
GASKETHELLA,4 300928
478
GASKETR & S,4 300928
480
LAMP SOCKETHELLA,4 300928
480
LAMP SOCKETR & S,4 300928
482
WASHER , Replaced By: A0005440476
482
WASHER ,4 300928
484
WASHER ,4 300928
486
GROMMET
486
GROMMET LINE PASSAGE AT SIDE MEMBER
488
BULB12 V/10 W
490
BULB12 V
492
TAIL LAMP LEFT "R & S"
492
TAIL LAMP LEFT "HELLA"
492
TAIL LAMP , Replaced By: A0025440203
492
TAIL LAMP , Replaced By: A0015447003, +001A0005441938, +002N072601012190, +001N072601012702
492
TAIL LAMP , Replaced By: A0025440403
492
TAIL LAMP , Replaced By: A0025440403
492
TAIL LAMP , Replaced By: A0015446803, +001A0005441838, +002N072601012190, +001N072601012702
492
TAIL LAMP RIGHT "R & S"
492
TAIL LAMP RIGHT "HELLA"
492
TAIL LAMP , Replaced By: A0015447103, +001A0005441838, +002N072601012190, +001N072601012702
492
TAIL LAMP , Replaced By: A0025440303
492
TAIL LAMP , Replaced By: A0025440303
492
TAIL LAMP , Replaced By: A0015446903, +001A0005441938, +002N072601012190, +001N072601012702
494
LENS''R&S''
494
LENS''HELLA''
496
GASKETR&S
496
GASKETHELLA
498
BULB12 V/10 W
500
BULB12 V
506
CABLE HARNESS TAIL LAMP
506
CABLE HARNESS , Replaced By: A6175401507
506
CABLE HARNESS , Replaced By: A6175400207
506
ELECTRIC CABLE , Replaced By: A6175400107
506
ELECTRIC CABLE , Replaced By: A0005401938
506
CABLE HARNESS RIGHT TAIL LAMP
506
CABLE HARNESS , Replaced By: A6215402207
506
ELECTRIC CABLE , Replaced By: A6175400307
508
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
510
WASHER EXHAUST MUFFLER TO STRAP
510
WASHER , Replaced By: N000125008443
512
NUT
514
WASHER TAIL LAMP TO SUPPORT
518
BRACKET TAIL LAMP,5 453766
518
BRACKET TAIL LAMP,5 453766
519
REFLECTOR
520
SCREW REFLECTOR TO BRACKET
522
WASHER BOOT TO CAB FLOOR
522
WASHER , Replaced By: N000433005304
524
LOCK WASHER BRACKET TO STEERING COLUMN END
526
NUT IN CASE OF SUBSEQUENT INSTALLATION
526
NUT , Replaced By: N304032005005
528
ANGLE LINE MOUNTING
528
BRACKET BATTERY CABLE,4 471135
530
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
532
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
536
BRACKET REFLECTOR
538
SCREW SHIFT CASE TO SLOTTED GATE
538
SCREW BRACKET TO TAIL LAMP BRACKET
540
WASHER COMPRESSED AIR LINE TO BRACKET
540
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
542
NUT OIL TANK TO BRACKET
542
NUT , Replaced By: N913002006009
550
NAME PLATE
552
SUPPORT
554
RIVET
556
SCREW CLAMP TO BRACKET AND TO PIPE
560
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
560
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
560
NUT , Replaced By: N913004008001
562
SCREW LICENSE PLATE TO BRACKET
566
NUT PUMP TO BRACKET
566
NUT , Replaced By: N913004006001
568
SCREW SUPPORT TO CROSS MEMBER M 10X28
568
SCREW REAR EXHAUST PIPE TO MUFFLER
570
NUT STRAP TO BRACKET
570
NUT , Replaced By: N910113010000
999
GROMMET ,4 940046 TO BE FILLED UP WITH SEALING MATERIAL TO BE ADAPTED DURING ASSEMBLY, Replaced By: A0005421181, +001A6155420140, +001A1139870044, +001A0019975086
999
DIAGRAM PAPER SET100 PIECES
