Поз.
Артикул
Описание
4
CLUTCH PRESSURE PLATE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
4
CLUTCH PRESSURE PLATE , Replaced By: A0032502504
10
SPRING SUSPENDED BELOW LEAF SPRING
10
SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
14
CLAMP RELEASE FLANGE TO RELEASE LEVER
18
PRESSURE PLATE
22
RELEASE LEVER CLUTCH ACTUATION
26
SPINDLE FOR BEDDING THE LEVERS IN CLUTCH PRESSURE PLATE
30
SPINDLE FOR BEDDING THE LEVERS IN BRACKETS
30
SPINDLE , Replaced By: A0002522816, +001A1249945241
34
ROLLER FOR BEDDING THE LEVERS IN BRACKETS
38
BRACKET RELEASE LEVER
42
LOCK PLATE RELEASE LEVER TO SHAFT
42
LOCK PLATE LEVER TO BRACKET
46
INSULATING WASHER
50
SLEEVE CLUTCH PRESSURE PLATE
54
FLANGE
54
FLANGE , Replaced By: A0002522145
58
SPRING SUSPENDED BELOW LEAF SPRING
58
SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
58
SPRING , Replaced By: A0002523227
62
PRESSURE SPRING SPRING STEEL WIRE DIA., 3.75 MM
64
PRESSURE SPRING SPRING STEEL WIRE DIA., 4.00 MM
68
LEAF SPRING THIGH SPRING SUSPENDED BELOW LEAF SPRING
68
LEAF SPRING THIGH SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
72
NUT FOR BRACKETS
72
NUT , Replaced By: A0002523072
76
LOCK FOR BRACKETS
80
LOCK WASHER BRACKET TO STEERING COLUMN END
84
SCREW RELEASE LEVER,BRACKET
84
SCREW STEP SWITCH AM 5X10
88
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
92
SCREW , Replaced By: N304017010055
92
SCREW , Replaced By: N304017010050
96
CLUTCH DISC
96
CLUTCH DISC , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0072500803
96
CLUTCH DISC , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0062504503
96
CLUTCH DISC
96
CLUTCH DISC , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0062504603
96
CLUTCH DISC , Replaced By: A0052506403
96
CLUTCH DISC , Replaced By: A0022509803
96
CLUTCH DISC ASBESTOS-FREE LINING, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
96
CLUTCH DISC ASBESTOS-FREE LINING
100
LEAF SPRING
100
LEAF SPRING , REBORE HOLE IN SUPPORTING PLATE FROM 5.2MM TO 6.2MM, Replaced By: A0002523819, +002A0002523975
104
RIVET LEAF SPRING TO CLUTCH DISC
104
RIVET LEAF SPRING TO CLUTCH DISC 5X6 MM
104
RIVET , Replaced By: A0002522075
108
CLUTCH LINING
108
CLUTCH LINING , Replaced By: A0012522910
108
CLUTCH LINING , Replaced By: A0012522910
108
CLUTCH LINING ASBESTOS-FREE
112
RIVET LINING WITH INTERMEDIATE SPRING,5 563495
112
RIVET LINING WITH INTERMEDIATE SPRING
112
RIVET , Replaced By: A0002521275
116
RIVET LINING WITH CLUTCH DISC,5 563495
116
RIVET LEAF SPRING TO CLUTCH DISC
999
PLUG BELL HOUSING
999
PRESSURE PLATE
999
CLAMP , Replaced By: A0002523227
999
HOUSING
999
LOCK
999
BOOT , Replaced By: A0005863129
999
PROTECTIVE CAP , Replaced By: A0004217187
999
PROTECTIVE CAP , Replaced By: A0004210887
999
PROTECTIVE CAP ,5 962906
999
VALVE , Replaced By: A3075530107
999
SEAL RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0019972141
999
SEAL RING CLUTCH ACTUATION
999
PIN CLUTCH ACTUATION
999
VALVE CLUTCH SLAVE CYLINDER
999
PROTECTIVE CAP , Replaced By: A0004210887
999
LEVER (PARTS KIT),CLUTCH ACTUATION
999
GREASE NIPPLE (PARTS KIT) RELEASE BEARING LUBRICATION
999
WASHER , Replaced By: N000125010532
999
WASHER RADIATOR TO RUBBER MOUNTING
999
LOCK RINGTO 000 553 37 01,000 553 39 01,
999
SCREW-IN FITTING RELEASE COLLAR LUBRICATION
999
SNAP RING LEVER TO RELEASE SHAFT,4 601609
