Поз.
Артикул
Описание
5
BRACKET STRAP WITH AIR CLEANER TO SUPPORT,4 900516
5
BRACKET ,4 900515, Replaced By: A6205204541, +001A3875201624
5
BRACKET STRAP WITH AIR CLEANER TO SUPPORT
8
STRAP ,4 900515
8
STRAP
10
SPLASH GUARD ,4 900515
10
SPLASH GUARD ,4 900515
12
SCREW , Replaced By: N304017006016
12
SCREW PUMP TO BRACKET
12
SCREW PUMP TO BRACKET
13
WASHER , Replaced By: N009021006208
13
WASHER COMPRESSED AIR LINE TO BRACKET
13
WASHER COMPRESSED AIR LINE TO BRACKET
14
NUT , Replaced By: N913004006001
14
NUT PUMP TO BRACKET
14
NUT PUMP TO BRACKET
999
SCREW COVER PLATE TO BRACKET
999
SPRING WASHER LICENSE PLATE TO BRACKET
999
ANTINOISE CAPSULE
999
ANTINOISE CAPSULE
999
BRACKET STRAP WITH AIR CLEANER TO SUPPORT
999
STRAP AIR CLEANER
999
BRACKET ,4 900515, Replaced By: A6205204641, +001A3875201724
999
BRACKET STRAP WITH AIR CLEANER TO SUPPORT
999
ANTINOISE CAPSULE AIR CLEANER
999
ANTINOISE CAPSULE AIR CLEANER,4 900516
999
STRAP ,4 900515
999
STRAP AIR CLEANER TO SUPPORT
999
STRAP
