Поз.
Артикул
Описание
7
PLASTIC PIPE AERATION, ORDER BY THE METER
7
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
14
FITTING , Replaced By: A0029905971
14
FITTING (PARTS KIT),LINE RUPTURE
16
BANJO UNION HOSE WIDTH, / I.D., 6/10 MM
18
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
21
BANJO UNION HEATING CONNECTION,K 169122
35
VALVE 3/2-WAY KNORR
35
VALVE 3/2-WAY BOSCH
35
VALVE 3/2-WAY WABCO
35
VALVE 3/2-WAY VOSS
42
SPRING INSIDE WABCO
49
SEAL RING INSIDE WABCO
56
SEAL RING TOP WABCO
63
HOLLOW SCREW LINE CONNECTION
70
SEAL RING LINE CONNECTION
77
NUT 4/3-WAY VALVE TO SUBSTRUCTURE
84
HOLLOW SCREW TWO-WAY VALVE,CONNECTIONS: "11,12"
91
SEAL RING FUEL LINE TO FEED PUMP
98
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 313530, Replaced By: A0012604957
98
VALVE SHUTTLE VALVE, REPAIR IMPOSSIBLE
105
HOLLOW SCREW , Replaced By: N915036010108
105
HOLLOW SCREW FUEL LINE TO FEED PUMP
112
SEAL RING FUEL LINE TO FEED PUMP
119
VALVE (PRESSURE RELIEF VALVE)
122
REPAIR KIT REDUCTION VALVE
126
HOLLOW SCREW HEATING CONNECTION
133
SEAL RING LINE CONNECTION
140
FITTING LINE CONNECTION
147
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
154
SEAL RING FUEL LINE TO FEED PUMP
161
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
168
FITTING BRAKE LINE COUPLING,"SUPPLY"
175
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
182
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
189
SEAL RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
196
THRUST RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
999
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION 6 MM
999
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
