Поз.
Артикул
Описание
5
CONSOLE REAR SPRING CENTRAL BEARING
8
SCREW
8
SCREW CONSOLE TO FRAME M 20X80
11
SCREW CONSOLE TO FRAME
11
SCREW BEARING BRACKET TO FRONT AXLE M 20X140,5 290346
14
NUT CONSOLE TO FRAME
17
SEAL RING PIPE ELBOW TO AIR CLEANER
20
THRUST WASHER CONSOLE,INSIDE
23
GASKET CONSOLE,OUTSIDE
26
SPRING SADDLE REAR SPRING CENTRAL BEARING
26
SPRING SADDLE REAR SPRING CENTRAL BEARING
26
SPRING SADDLE REAR SPRING CENTRAL BEARING
29
TAPERED ROLLER BEARING SPRING SADDLE,INSIDE
29
TAPERED ROLLER BEARING SPRING SADDLE,INSIDE
29
TAPERED ROLLER BEARING SPRING SADDLE,INSIDE
29
TAPERED ROLLER BEARING SPRING SADDLE,INSIDE
32
SEAL RING INSIDE
35
SEAL RING OUTSIDE
38
TAPERED ROLLER BEARING SPRING SADDLE,OUTSIDE
38
TAPERED ROLLER BEARING SPRING SADDLE,OUTSIDE
38
TAPERED ROLLER BEARING SPRING SADDLE,OUTSIDE
41
SPACER WASHER SPRING SADDLE TO CONSOLE
44
NUT SPRING SADDLE TO CONSOLE
47
GASKET TO LOCK SPRING SADDLE
50
COVER TO LOCK SPRING SADDLE
53
SCREW BRACKET TO BATTERY/APPARATUS SUPPORT
53
SCREW CLAMP TO BRACKET AND TO PIPE
56
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
59
SCREW PLUG , Replaced By: N007604014110
62
SEAL RINGTO 000 553 03 05,000 553 18 05,
