Поз.
Артикул
Описание
20
HOUSING
20
HOUSING , Replaced By: A4471310215, +001A4471310121, +001A4471310280, +002N000931008210
20
HOUSING , Replaced By: A4071300610
30
THREADED INSERT
35
THREADED INSERT ,5 462573
40
SPACER TUBE
45
DRIVE GEAR ON AIR COMPRESSOR CRANKSHAFT
45
DRIVE GEAR ON AIR COMPRESSOR CRANKSHAFT
47
CRANKSHAFT
47
CRANKSHAFT , Replaced By: A4031310716
47
CRANKSHAFT , 401-403,421-423,440-443,445,446888000 407,427,447062251, Replaced By: A4031311216, +001A4071300445, +001A0001321410
47
CRANKSHAFT , Replaced By: A4031300214
48
CLAMPING SLEEVETO 001 430 66 81,001 430 67 818KNORR
50
SCREW DRIVE GEAR TO CRANKSHAFT
55
SELF-ALGN.ROLLER BEARING DRIVE GEAR TO CRANKSHAFT
55
SELF-ALGN.ROLLER BEARING , Replaced By: A0009810535
55
CYLINDR. ROLLER BEARING , Replaced By: A0079813001
55
CYLINDR. ROLLER BEARING AIR COMPRESSOR BEARING
60
LOCK BEARING FLANGE IN TIMING CASE & AIR COMPRESSOR HOUSING,RESP.
65
FLANGE AIR COMPRESSOR,424.900-000-012333
65
FLANGE
70
BUSHING , Replaced By: A0001314250
70
BUSHING
75
SEAL RINGTO 388 476 71 69
75
SEAL RING , Replaced By: A0149976148
77
SCREW BRACKET TO SIDE MEMBER M10X35
77
HEXAGON HEAD BOLT BRACKET TO BRACKET M10X35
77
HEXAGON HEAD BOLT CONSOLE TO REAR CROSS MEMBER AND TO FRAME SIDE MEMBERS M 10X40
79
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
85
CAP COVER TO AIR COMPRESSOR HOUSING,048083048474
85
CAP COVER TO AIR COMPRESSOR HOUSING
90
GASKET COVER TO AIR COMPRESSOR HOUSING
90
SEAL RING COVER TO AIR COMPRESSOR HOUSING
95
CAP TO PLUG AIR COMPRESSOR OPENING,128243
100
GASKET OIL FILTER TO CYLINDER CRANKCASE
100
GASKET OIL FILTER TO CYLINDER CRANKCASE
100
GASKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4421312080
100
GASKET TO PLUG AIR COMPRESSOR CONNECTION ON CYLINDER CRANKCASE
105
SCREW STOP TO BATTERY CASE
110
SCREW CLUTCH TO FLYWHEEL,760271
115
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
115
SPRING WASHER , Replaced By: N000137008212
120
CONNECTING ROD
120
CONNECTING ROD , LESS CONNECTING ROD BEARING SHELLS - BEARING SHELLS NO LONGERREQUIRED
125
CLAMPING SLEEVE
130
SCREW THERMOSTAT HOUSING TO WATER PUMP M 8X38
135
BEARING SHELL UPPER AND LOWER HALVES
140
CYLINDER LINER WITH PISTON
145
PISTON RING GROOVES I AND II
150
PISTON RING GROOVE III
155
PISTON PINTO 403 130 05 17
160
SNAP RING
165
EXPANSION PLUG P.T.O. HOUSING
170
FITTING FROM INTAKE MANIFOLD TO VACUUM LINE, FROM IDENT NO.002799-360785
175
SEAL RING FROM FUEL TANK TO FUEL TANK
180
GASKET OIL FILTER TO CYLINDER CRANKCASE
180
GASKET OIL FILTER TO CYLINDER CRANKCASE
180
GASKET , Replaced By: A4421312080
180
GASKET TO PLUG AIR COMPRESSOR CONNECTION ON CYLINDER CRANKCASE
185
HEXAGON HEAD BOLT. SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
188
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
190
WASHER EXHAUST MUFFLER TO STRAP
195
CYLINDER HEAD LESS DISC VALVE
195
CYLINDER HEAD WITH DISC VALVE, 407 030936 427 002637 447.901/200 030936 447.905/906/908/910/911/912/951 001443
200
THREADED INSERT REPAIR SIZE, TO BE ADAPTED DURING ASSEMBLY
205
GASKET
205
GASKET INTERMEDIATE PLATE TO CYLINDER HEAD
205
GASKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4421311980
205
GASKET , Replaced By: A4421312180
205
GASKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4421312980
210
SCREWTO 376 131 74 01
215
GASKET CYLINDER HEAD TO CYLINDER LINER
215
GASKETWABCO
220
HEXALOBULAR BOLT BRACKET TO SUPPORT M8X80
220
HEXAGON HEAD BOLT. SCREW , Replaced By: N910143008016
222
SPRING WASHER , Replaced By: N000137008212
222
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
225
SCREW PLUG OIL COOLER,5 360280
225
SCREW PLUG , Replaced By: N000908026008
225
SCREW PLUG , Replaced By: A0009973532
230
SEAL RING FROM PIPE ELBOW TO AIR COMPRESSOR
235
SCREW PLUGTO 000 553 03 05,000 553 18 05,
235
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
235
SCREW PLUG , Replaced By: N000908014009
235
SCREW PLUG , Replaced By: N000908022011
240
ADAPTER FITTINGTO 376 131 74 01
242
SEAL RINGTO 376 131 74 01
242
SEAL RING INJECTION PUMP
245
VALVE DISCTO 002 131 36 01
250
VALVE AIR COMPRESSOR CYLINDER HEAD TO 000 130 24 19/25 19/26 19
250
REPAIR KIT , Replaced By: A4421300720
250
PARTS KIT AIR COMPRESSOR CYLINDER HEAD
255
GEAR DRIVE GEAR ON CAMSHAFT
258
SCREW CONNECTOR TO REAR SHIFTING ROD
260
GASKET
263
SCREW FAN TO CRANKSHAFT PULLEY
266
SCREW EXHAUST PIPE TO MUFFLER AND TO HEATER UNIT M 8X55
269
SCREW WATER PUMP COVER TO WATER PUMP HOUSING M 8X28
269
SCREW BRACKET TO EXHAUST PIPE BRACKET
269
SCREW , Replaced By: N304017008024
272
SPRING WASHER , Replaced By: N000137008212
272
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
275
FITTING FROM INTAKE MANIFOLD TO VACUUM LINE, FROM IDENT NO.002799-360785
999
GASKET , Replaced By: A4421310980
999
GASKET , Replaced By: A0011317380
999
SEALANT , Replaced By: A0019892920
999
GASKET , Replaced By: A4421310080
999
GASKET
999
GASKET , Replaced By: A4421311980
999
GASKET , Replaced By: A4421310680
999
CYLINDER LINER , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 401-403 264430 404 006644 407 028975 421-423 129290 424 002427 427 000747, Replaced By: A4021300608
999
REPAIR KIT , Replaced By: A0001307620
999
REPAIR KIT , Replaced By: A4421300720
