Поз.
Артикул
Описание
8
COVER OIL FILTER, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
8
HOUSING OIL COOLER, ORDER ADDITIONALLY: N 000908 030002 U. N 0076030030400
8
HOUSING ,783977, Replaced By: A4421881304, +001N000931008254, +001N000931010122
8
HOUSING , Replaced By: A4421881604
8
HOUSING , Replaced By: A4421881804
8
HOUSING , Replaced By: A4571880504
12
THREADED INSERT DE-AERATION LINE TO COOLING WATER LINE
12
THREADED INSERT REPAIR SIZE, TO BE ADAPTED DURING ASSEMBLY
17
THREADED INSERT
20
COVER , 401/402/441-443793440 444016364
20
COVER , 401/402/441-443793439 444016363, Replaced By: A4421840708, +001A0045428917, +001N007603014106
23
SCREW PLUG BELL HOUSING TO 620 251 07 01,620 251 16 01, 426,427,428,521,522 5 095724 532 5 104253
26
SEAL RING TEMPERATURE GAUGE SENDER UNIT
29
SCREW PLUG
29
SCREW PLUG FUEL TANK
32
SEAL RING SOLENOID VALVE A 18X24
32
SEAL RINGTO 000 553 03 05,000 553 18 05,
33
SCREW PLUG
34
SEAL RING OIL LINE TO OIL COOLER
35
GASKET
38
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
38
BOLT. SCREW BRACKET TO PUSH ROD CHAMBER COVER
41
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
44
FILTER BOWL
47
SPRING
49
EXPANSION PLUG
50
CAP. EXPANSION PLUG SHAFT
61
SEAL RING OIL FILTER HEAD TO CYLINDER CRANKCASE FRONT SIDE 39.2X3
65
SCREW OIL FILTER HEAD TO CYLINDER CRANKCASE FRONT SIDE
66
SEAL RING OIL FILTER HEAD TO CYLINDER CRANKCASE FRONT SIDE 26.2X3
68
SCREW BRACKET TO SIDE MEMBER
68
SCREW BELL HOUSING TO NMV M 10X135
68
STUD BOLT BEARING COVER TO TRANSMISSION CASE, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
68
SCREW , Replaced By: N304017010002
68
SCREW , Replaced By: N910105010017
71
SPRING WASHER STEERING COLUMN BRACKET TO CAB
72
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
77
HOUSING OIL FILTER BOWL
77
FILTER BOWL OIL FILTER BOWL
80
SCREW PLUG SHIFTING SHAFT DETENT
83
SEAL RING VALVE TO VALVE,K 025179
89
FILTER ELEMENT WITH GASKETS
89
FILTER ELEMENT RANGE OF DELIVERY
89
FILTER ELEMENT WITH GASKETS
89
FILTER ELEMENT WITH GASKETS
95
SEAL RING FILTER BOWL TO FILTER HEAD
95
SEAL RING OIL FILTER BOWL WITH FULL-FLOW FILTER TO OIL FILTER HEAD
95
SEAL RING BRAKE CYLINDER STROKE INDICATOR
98
SEAL RING OIL DRAIN 26X34 MM
101
SEAL RING FUEL LINE TO FEED PUMP
107
SCREW
107
SCREW OIL FILTER BOWL WITH FULL-FLOW FILTER TO OIL FILTER HEAD
110
VALVE
113
SPRING BY-PASS VALVE
116
SCREW PLUG
119
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
123
SCREW PLUG
125
SEAL RING OIL DRAIN 26X34 MM
131
SCREW PLUG, FILLING OIL DRAIN
131
SCREW PLUG FUEL TANK
134
SEAL RINGTO 000 553 03 05,000 553 18 05,
134
SEALING RING. SEAL RING ENGINE BREATHING
140
OIL COOLER , ORDER NUMBER: 001 188 89 01/33
140
OIL COOLER
140
OIL COOLER , ORDER NUMBER: 001 188 88 01/33
140
OIL COOLER , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 749024, Replaced By: A0021884301
140
OIL COOLER , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 749024, Replaced By: A0021884301
143
SEAL. GASKET , Replaced By: A3661880880
146
SCREW VALVE TO BRACKET
146
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
146
SCREW ON STOP M 8X65
146
SCREW CABLE HARNESS MOUNTING
146
HEXALOBULAR BOLT. SCREW SUPPORT TO CYLINDER HEAD
146
SCREW PLUG SOCKET TO BRACKET BEHIND CAB
146
SCREW VALVE TO BRACKET, Replaced By: N304014008002
152
GASKET , Replaced By: A4421880580
152
GASKET OIL FILTER HEAD & OIL COOLER COVER WITH OIL COOLER TO CRANKCASE
155
SCREW SHIFTING ROD TO SHIFT LEVER
155
SCREW STEERING SUPPORT TO FRAME M 10X75
155
SCREW PIPE ELBOW TO BRACKET M 10X50
155
HEXAGON HEAD BOLT P.T.O. TO TRANSMISSION M10X150
155
SCREW CONNECTOR TO REAR SHIFTING ROD
155
SCREW , Replaced By: N304017010053
160
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
999
SPRING WASHER , Replaced By: N000137008212
999
NUT , Replaced By: N913023010002
