27 AUTOMATIC TRANSMISSION
›
001 MB AUTO TRANSMISS.ATTACHMENT PARTS IL.1
Mercedes N000933006102 - SCHRAUBE
308/310 602.021
27 AUTOMATIC TRANSMISSION - 001 MB AUTO TRANSMISS.ATTACHMENT PARTS IL.1
Поз.
Артикул
Описание
313
A6013101546
CROSS MEMBER REAR
315
A6013100490
STIFFENING REAR CROSS MEMBER TO SIDE MEMBERS
340
A6013102218
SIDE MEMBER REAR LEFT
345
A6013200475
SPRING BRACKET FRONT LEFT
350
A6013102318
SIDE MEMBER REAR RIGHT
366
A6013200775
SPRING BRACKET FRONT RIGHT
368
A6013250203
REAR SPRING BRACKET REAR LEFT AND RIGHT
372
A6013150061
EYE AT LEFT SPRING BRACKET
374
A6014001339
BRACKET
416
A6013170631
COVER PLATE AT REAR CROSS MENBER
420
N000933006102
SCREW COVER PLATE TO BRACKET
424
N000137006204
SPRING WASHER LICENSE PLATE TO BRACKET
428
A0019904191
NUT RETAINER COVER PLATE TO REAR CROSS MEMBER
432
N000934006007
NUT BALL PIVOT TO LEVER
436
A6019880311
BUFFER AT REAR CROSS MENBER, 711813 P 000001
440
N910113008001
NUT STRAP TO BRACKET
999
A6013100068
RAIL RIGHT
999
A6013120854
COVER AT CROSS MEMBER
