Поз.
Артикул
Описание
5
TRANSMISSION CASE COVER GEARSHIFT MECHANISM
11
GASKET LATERAL, WITH AK 6-90 UP TO TRANSMISSION 068147,WITH AK 6-80 UP TO TRANSMISSION 279573
11
GASKET , Replaced By: A3432650679
11
GASKET , Replaced By: A0002650280
14
SCREW , Replaced By: N304017010050
14
SCREW , Replaced By: N304014010004
14
SCREW CLUTCH TO FLYWHEEL
14
HEXAGON HEAD BOLT CLAMP TO EXHAUST PIPE
14
SCREW MOUNTING AND RAIL TO LEAF SPRING
14
SCREW STRAP TO BRACKET
14
SCREW , Replaced By: N304017010055
17
SPRING WASHER STEERING COLUMN BRACKET TO CAB
20
SHAFT (SHIFTING SHAFT),070291,S 6-80304634,AK 6-80
20
SHAFT ,049275,S 6-80279573,AK 6-80, Replaced By: A0002681232, +001A0002684130, +001A3362680257, +001A0039940141, +001N000137010201, +001N000931010309, +001N000934010009
20
SHAFT , 018183,S 6-90 068148, AK 6-90, Replaced By: A0002681232, +001A0002684130, +001A3362680257, +001N000137010201, +001N000931010306, +001N000934010009
23
ROLLER SHIFTING SHAFT
26
FOLLOWER TOP
29
SPACER RING SHIFTING SHAFT,BOTTOM
32
FOLLOWER REVERSE SPEED
32
FOLLOWER SHIFTING SHAFT
35
SHIFTING SEGMENT , Replaced By: A0002680446
35
SHIFTING SEGMENT , Replaced By: A0002680246
35
SHIFTING SEGMENT SHIFTING SHAFT
38
CLAMPING SLEEVE FOLLOWER TO SHIFTING SHAFT
41
CLAMPING SLEEVE FOLLOWER TO SHIFTING SHAFT
50
SPRING SHIFTING SHAFT
53
SPACER WASHER SHIFTING SHAFT
56
LOCK RING
56
LOCK SHIFTING SHAFT
56
LOCK , Replaced By: A0039940141
59
COVER SHIFT LEVER TO TRANSMISSION
62
SHIFT LEVER
62
SHIFT LEVER , Replaced By: A0002682730
62
SHIFT LEVER , Replaced By: A0002684130
65
SCREW SHIFTING ROD TO JOINT
68
SPRING WASHER STEERING COLUMN BRACKET TO CAB
71
NUT
71
NUT , Replaced By: N304032010002
74
JOINT , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0002684889
74
JOINT SHIFTING SHAFT,TOP
77
NUT BRACKET TO SIDE MEMBER,K 035196
77
NUT , Replaced By: N308673014001
80
CONNECTOR , Replaced By: A0002680428
80
CONNECTOR SHIFTING TUBE TO SHIFT LEVER
83
NUT , Replaced By: N913004016005
86
PULL ROD , TO BE ADAPTED DURING ASSEMBLY
86
SHIFTING ROD , Replaced By: N900331012273
89
NUT PULL ROD
92
NUT STRAP TO SUPPORT,5 149419
95
JOINT TOP
95
JOINT , Replaced By: A0002686189
95
JOINT , Replaced By: A0002684789
98
JOINT , Replaced By: A0002686289
98
JOINT , Replaced By: A0002684689
98
JOINT BOTTOM
104
BRACKET BRACING,003528,5 S 90 GPA001871,5 K 90 GPA
113
NUT , Replaced By: N913004016005
116
NUT , Replaced By: A0002680472
116
NUT , Replaced By: N913004010010
116
NUT , Replaced By: N910113010002
116
HEXAGON NUT
191
SHAFT SHIFT CASE
194
PIN , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0002683974
194
PIN SHIFT CASE,BOTTOM
197
SPRING SHIFT CASE
200
HOUSING ,074784, Replaced By: A0002683701, +001A0119972246, +004N000933008082
200
HOUSING SHIFTING DOME
203
SEAL RING SHIFTING SHAFT
206
BOOT SHIFTING SHAFT
209
SEAL RING SHIFTING DOME TO 000 268 12 01
209
SEAL RING SHIFTING DOME,TOP
212
NEEDLE BEARING , THE OLD PART MUST NO LONGER BE INSTALLED THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0002682150
212
BUSHING SHIFTING DOME,TOP
215
NEEDLE BEARING REAR DRIVE SHAFT
215
NEEDLE BEARING , THE OLD PART MUST NO LONGER BE INSTALLED THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0002682150
218
COVER SHIFT CASE,BOTTOM
218
COVER SHIFT CASE,BOTTOM
221
GASKET , Replaced By: A0002685180
221
GASKET SHIFT CASE,TOP AND BOTTOM
224
SCREW REINFORCEMENT TO CROSS MEMBER,5 101104
224
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
224
SCREW SUPPORT TO FENDER
224
SCREW , Replaced By: N000933008337
224
SCREW , Replaced By: N304017008018
224
SCREW , Replaced By: A0099900101
227
SPRING WASHER , Replaced By: N000137008212
227
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
230
BREATHER , Replaced By: A3432640089
230
VALVE BREATHER, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
233
COVER SHIFT CASE,BOTTOM
236
SPACER WASHER SHIFT CASE
239
PIN SHIFTING SHAFT
239
PIN , Replaced By: A0002670474
242
SPRING SHIFTING DOME
266
DETENT TRANSMISSION CASE
266
DETENT , Replaced By: A0002601873
266
STOP , Replaced By: A0002600273
269
LOCK PLATE SHIFT CASE
272
PIN
290
SCREW PLUG
296
SCREW PLUG BELL HOUSING
296
PLUG , Replaced By: A0009973435
296
PLUG , Replaced By: A0009977535
296
PLUG , Replaced By: A3529970032
296
COVER , Replaced By: A0009977535
299
COVER , Replaced By: A0009971120
299
EXPANSION PLUG HOUSING,BOTTOM
