Поз.
Артикул
Описание
5
WHEEL BRAKE CYLINDER (DIAPHRAGM CYLINDER) WABCO
5
WHEEL BRAKE CYLINDER
5
WHEEL BRAKE CYLINDER , Replaced By: A0074208718
8
SPRINGTO 017 420 22 18/23 18
17
REPAIR KITTO 007 420 87 18,WABCO, NOT USED
20
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
23
PIN COMBINATION CYLINDER TO SLACK ADJUSTER
26
WASHER SHIFT LEVER TO PIVOT PIN
29
COTTER PIN STRAP TO SUPPORT
32
ADJUSTER SLACK ADJUSTER
35
CONTROL UNIT
38
WORM GEAR"SAB"
41
WORM SCREW"SAB"
44
REPAIR KIT SLACK ADJUSTER "SAB"
47
STOP WASHER SLACK ADJUSTER TO BRAKE SHAFT
50
SPACER WASHER ADJUSTER,AS REQUIRED 0.50 MM
50
SPACER WASHER ADJUSTER,AS REQUIRED 2.50 MM
50
SPACER WASHER ADJUSTER,AS REQUIRED 2.00 MM
50
SPACER WASHER ADJUSTER,AS REQUIRED 1.50 MM
53
SPACER WASHER ADJUSTER
56
LOCK RING ADJUSTER TO BRAKE CAMSHAFT
59
WASHER , Replaced By: N000125008443
62
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
65
SCREW CLAMP TO BRACKET AND TO PIPE
65
SCREW IGNITION COIL TO BRACKET
68
FITTED WASHER SLACK ADJUSTER TO BEARING BRACKET
68
FITTED WASHER SLACK ADJUSTER TO BEARING BRACKET
71
BRAKE ANCHOR RIGHT BRAKE SHAFT
71
BRAKE ANCHOR LEFT BRAKE SHAFT
74
BUSHING BRAKE CAMSHAFT BEARING,INSIDE
74
BUSHING OUTSIDE
77
BUSHING INSIDE
77
BUSHING BRAKE CAMSHAFT BEARING,OUTSIDE
80
SEAL RING INSIDE BEARING BRACKET
80
SEAL RING INSIDE BEARING BRACKET
80
SEAL RING BRAKE CAMSHAFT BEARING IN CASE
83
SEAL RING OUTSIDE BEARING BRACKET
83
SEAL RING BRAKE CAMSHAFT BEARING
83
SEAL RING OUTSIDE BEARING BRACKET
83
SEAL RING OUTSIDE BEARING BRACKET
86
GREASE NIPPLE INTERMEDIATE LEVER
89
SCREW BEARING BRACKET TO BRAKE ANCHOR
92
NUT WITH COLLAR
92
NUT BEARING BRACKET TO BRAKE ANCHOR
92
NUT , Replaced By: A0009905750
999
REPAIR KITTO 007 420 33 18,KNORR
