Mercedes
AXLE
HD 7/19 DG-13
740.042 PRODUKTION KASSEL
42 REAR BRAKE
001 REAR AXLE WITH DIFF. LOCK (OUTSIDE PLANETARY GEAR (APL) AXLE)

HD 7/19 DG-13 - 740.042 PRODUKTION KASSEL - 42 REAR BRAKE

Поз.
Артикул
Описание
10
A3463350073
LOCK FOLLOWER
15
A3553500011
DIFFERENTIAL LOCK PARTS KIT
15
A3553530536
FOLLOWER , Replaced By: A3553500011
15
A3553530636
FOLLOWER , Replaced By: A3553500011
16
A3553530334
SHIFTING FORK ,167955, Replaced By: A3553531334
16
A3553531334
SHIFTING FORK DIFFERENTIAL LOCK
18
N000007010309
CYLINDRICAL PIN DIFFERENTIAL LOCK,167955
20
A3469930901
SPRING SHIFTING FORK
22
A3463530535
SHAFT SHIFTING ROD,232175
22
A3463530235
SHAFT ,232174, Replaced By: A3463530535, +001N000551010006
24
N000551010010
HEADLESS SETSCREWM 10X20,232174
24
N000551010006
HEADLESS SETSCREWM 10X25,232175
26
N304035010002
NUT CLUTCH OPERATION
26
N000936010023
NUT , Replaced By: N304035010002
28
A3463530155
CYLINDER , Replaced By: A3463530655, +003N000931008278, +001N007603018100
28
A3463530255
CYLINDER (SHIFTING CYLINDER)
28
A3463530655
CYLINDER TRANSVERSE DIFFERENTIAL LOCK
30
A3463530357
PISTON TRANSVERSE DIFFERENTIAL LOCK
30
A3463530257
PISTON CYLINDER
30
A3463530157
PISTON TRANSVERSE DIFFERENTIAL LOCK
32
A0019972245
SEAL RING SHIFTING CYLINDER
33
A3463530108
COVER SHIFTING CYLINDER,009640
34
A3463530508
COVER , Replaced By: A3463530455
34
A3463530655
CYLINDER TRANSVERSE DIFFERENTIAL LOCK
34
A3463530408
COVER , Replaced By: A3463530655
36
A3553510080
GASKET , Replaced By: A3553530280
36
A3553530280
GASKET DIFFERENTIAL LOCK TO 355 353 02 80
38
N304017008053
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL
38
N304017008028
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
38
N000933008248
SCREW CYLINDER 8X60
38
N304014008001
SCREW FRONT AXLE REGULATING SOLENOID VALVE M 8X75
38
N000931008246
SCREW PLUG SOCKET TO BRACKET BEHIND CAB
38
N000931008248
SCREW , Replaced By: N304017008053
38
N304014008004
SCREW , Replaced By: N304014008001
40
A3469970545
SEAL RING SWITCH, UP TO REAR AXLE 009640
40
N007603018100
SEAL RING SWITCH TO CASE COVER
42
A0015454714
SWITCH , Replaced By: A0015455709
42
A0015458214
SWITCH
42
A0005454214
SWITCH , Replaced By: A0015458214
44
A0005455011
SWITCH SOLENOID VALVE
48
A3275450274
PIN TWO-SPEED REAR AXLE
50
A6593571301
REAR AXLE SHAFT WITH INTERLOCK SERRATIONS, LKW W972500, BUS W974541, V000001
50
A6593571101
REAR AXLE SHAFT WITH INTERLOCK SERRATIONS
50
A3553571001
REAR AXLE SHAFT WITH INTERLOCK SERRATIONS
50
A3553570801
REAR AXLE SHAFT WITH INTERLOCK SERRATIONS, LKW W972499, BUS W974540
50
A6193570101
REAR AXLE SHAFT WITH INTERLOCK SERRATIONS
50
A3073570101
REAR AXLE SHAFT , Replaced By: A6593571101, +001N009045042001
50
A6193570001
REAR AXLE SHAFT , LKW W972499, BUS W974540, Replaced By: A6193570101
50
A6193570301
REAR AXLE SHAFT , Replaced By: A6593571301, +001N009045042001
999
A3553531545
COVER
999
A3553570701
REAR AXLE SHAFT , LKW W972499, BUS W974540
999
A3553571101
REAR AXLE SHAFT
